Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
Specifications
Brand Name :
KEGU
Place of Origin :
China
Price :
200-500 yuan/kg
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
2,000 pcs/month
Packaging Details :
Strong wooden box for Global shipping
Model Number :
Customizable
Material :
Silicon Nitride
Composition:SiC :
＞85%
Color :
Black
Density :
3.20-3.26g/cm3
Max. Service Temp :
1450℃
Flexural Strength :
250MPa
Sample :
Customizable
Chemical Stability :
High
Apparent Porosity :
0-0.1%
Elastic Modulus :
300-320GPa
Compression Strength :
>1500MPa
Vickers Hardness(HV0.5) :
15-16GPa
Thermal Conductivity :
20-25W/(m.k)
Specific Resistivity :
10^14Ω·cm
Description

Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural

High-performance silicon nitride ceramic materials developed for the aluminum industry has significantly improved thermal and mechanical properties than similar products. On this basis, the "L-shaped high thermal conductivity submerged heating "Appliance" will bring revolutionary progress to aluminum industrial equipment.

Special structural parts with high requirements for thermal shock resistance are areas where silicon nitride ceramic materials can be vigorously developed in the future. In application areas with high temperature, strong corrosion, and high wear resistance, silicon nitride ceramics are used to replace some cemented carbide, alumina, Materials such as zirconia and silicon carbide will become a trend.

Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural

Silicon Nitride Related Data

Main component 99%Al2O3 S-SiC ZrO2 Si3N4
Physical
Property		 Density g/cm3 3.9 3.1 6 3.2
Water Absorption % 0 0.1 0 0.1
Sinter Temperature °C 1700 2200 1500 1800
Mechanical
Property		 Rockwell Hardness HV 1700 2200 1300 1400
Bend Strength kgf/mm2 3500 4000 9000 7000
Compression Intensity Kgf/mm2 30000 20000 20000 23000
Thermal
Property		 Maximum working
temperature		 °C 1500 1600 1300 1400
thermal expansion
coefficient
0-1000°C		 /°C 8.0*10-6 4.1*10-6(0-500°C) 9.5*10-6 2.0*10-6(0-500°C)
5.2*10-6(500-1000°C) 4.0*10-6(500-1000°C)
Thermal Shock resistance T(°C) 200 250 300 400-500
Thermal Conductivity W/m.k(25°C 31 100 3 25
300°C) 16 100 3 25
Electrical
Property		 Resisting rate of Volume ◎.cm 　 　 　 　
20°C >1012 106-108 >1010 >1011
100°C 1012-1013 – – >1011
300°C >1012 – – >1011
Insulation Breakdown
Intensity		 KV/mm 18 semiconductor 9 17.7
Dielectric Constant (1 MHz) (E) 10 – 29 7
Dielectric Dissipation (tg o) 0.4*10-3 – – –

Black OEM Si3N4 Silicon Nitride Ceramics Non Standard Structural
