(i)Dieletric Antenna

1. Center Frequency :1575.42MHz±3 MHz

2. V.S.W.R : 1.5:1

3. Band Width :±5 MHz

4. Impendence :50 ohm

5. Peak Gain :＞3dBic Based on 7×7cm ground plane

6. Gain Coverage :＞-4dBic at –90°＜0＜+90°(over 75% Volume)

7. Polarization :RHCP


(ii)GSM Antenna

1. Center Frequency :824MHz~894MHz(AMPS) , 880 MHz~960MHz(GSM), 1710MHz~1990MHz
2. V.S.W.R :2.0:1
3. Impendence :50 ohm
4. Typical Gain :2dBi+/-1dB@850MHZ; 2dBi+/-1dB@900MHZ;

1dBi+/-1dB@1800MHZ; 1dBi+/-1dB@1900MHZ

(iii)Wifi Antenna

1. Frequency Range :2400-2500 MHz
2. VSWR :≤1.5
3. Gain :2.15dBi
4. Impedance :50 ohm
5. Polarization Type ；Vertical


(iv)LNA/Filter

1. LNA Gain(Without cable) :28dB Typical

2. Noise Figure :1.5dB

3. Filter Out Band Attenuation :(f0=1575.42 MHZ)

4. 7dB Ｍin f0+/-20MHZ ;

5. 20dB Ｍin f0+/-50MHZ;

6. 30dB Ｍin f0+/-100MHZ

7. V.S.W.R ＜2.0

8. DC Voltage : 2.7V/3.0V/3.3V/5.0V/3.0V to 5.0V/other

9. DC Current : 11mA Max


(v)Mechanical

Weight :＜240gram
Size :70mmx70mmx14mm
Cable
GPS-----RG174 2meter, 5meter long or other
GSM-----RG174 2meter, 5meter long or other
Wifi-----RG174 2meter, 5meter long or other
Connector
GPS-----SMA/SMB/SMC/BNC/FME/TNC/MCX /MMCX or other
GSM-----SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX or other
Wifi-----SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX or other
Mounting:Screw Mounting
Housing :Black

(v) Environmental

1. Working Temp. :-40℃~+85℃

2. Storage Temp. :-45℃~+100℃

3. Vibration :Sine sweep 1g(0-p)10~50~10Hz each axis

4. Humidity :Humidity95%~100%RH

5. Weatherproof :100%Waterproof
