7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness
Specifications
Brand Name :
OEM/Customized
Model Number :
ZH070TH001-03A
Certification :
ROHS、ISO9001、CE
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
500K pcs/ Month
Delivery Time :
7-15 working days
Packaging Details :
Foam Cotton And Carton Boxes
Size :
7.0 Inch
Resolution :
1200x1920
Brightness :
2000 cd/m² （Typ.）
Display type :
IPS, Normally Black
Outline Dimensions :
111.0(W) x166.0(H) x3.29(T) mm
Operating Temperature :
-20℃~+70℃
Description

7 Inch HD TFT LCD Display 1200x1920 Resolution with 2000nits Brightness

The ZH070TH001-03A is 7 Inch HD TFT LCD Display, engineered to deliver stunning visuals in environments requiring high brightness and clarity. With a 2000 cd/m² brightness and IPS technology, this display ensures high-quality, vibrant images with exceptional clarity under direct sunlight or in challenging lighting conditions. Ideal for industrial systems, automotive applications, outdoor signage, and interactive kiosks, this display is built to excel in demanding commercial and industrial settings.

The ZH070TH001-03A HD TFT LCD Display is an ideal solution for businesses and industries requiring a high-performance display that delivers exceptional clarity, brightness, and reliability. Here’s why it’s the best choice for your next project:

High Brightness: With 2000 cd/m², this display ensures excellent visibility even in direct sunlight, making it perfect for outdoor applications.

Durable and Reliable: The wide operating temperature range from -20℃ to +70℃ ensures that the display performs reliably in harsh environments, whether outdoors or in industrial settings.

Energy Efficient: Thanks to its LED backlight technology, this display delivers high brightness with low power consumption, helping reduce energy costs and extend the lifespan.

Versatile Integration: The compact dimensions and optional touch panel allow easy integration into a wide variety of interactive and non-interactive applications.

Long Lifetime: With an impressive 50,000 hours lifetime, this display offers long-term value and reliability, making it ideal for applications that require sustained performance.

Product Specification

item ZH070TH001-03A
Screen Size 7.0 Inch
Resolution 1200x1920
Brightness 2000 cd/m²(Typ.)
Display Mode IPS, Normally Black
Interface MIPI, 40pins Connector
Active Aera 94.5(W) x 151.2(H) mm
Outline Dimension 111.0(W) x166.0(H) x3.29(T) mm
Backlight 56-Chip white LED, 400mA 21V
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Touch Panel Optional Touch Panel

Product Drawing

7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness

7 Inch HD TFT LCD Display Screen 1200x1920 Resolution With 2000nits Brightness

Why Choose ZhanHui TFT LCD Screen?

  • Having been dedicated to industrial vehicle-mounted LCD module applications for 10 years
  • A powerful engineering support team offers a one-stop integrated solution
  • Flexible and efficient customization capabilities, with rapid response to demands
  • Strict quality control system (such as through IATF 16949, ISO 9001)
  • Global logistics and localized service support
  • Highly competitive cost-effectiveness

FQA

1. What is the minimum order quantity?
All our models have MOQ requirements, please get in touch with our salesman for detailed information.

2. Can I take one piece for sample to test the quality?

Yes, We recommend checking the sample before order. You could order the sample before your order.

3. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

4.What can you buy from us?
LCD Modules,LCD Display Screen,High Brightness TFT LCD Display,Touch Screen,OLED Display

5. Why should you buy from us not from other suppliers?
One of the things that sets us apart from other TFT LCD & PCAP touch modules manufacturers is the level of customization we offer. There is no limit to what we can create when we take on a custom project!

Call to Action :

  • Upgrade your device visibility with this premium TFT LCD Module!

  • Request a Quote Today!

  • Download Full Datasheet (Link)

  • Contact Sales for Volume Pricing

  • Order Samples Now!
