Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
Specifications
Brand Name :
Anycut
Model Number :
ZKSV350
Certification :
CE/FCC/RoHS
Place of Origin :
shenzhen
MOQ :
1
Price :
$856~1255/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L780mm*W580mm*H520mm
support softeware :
CDR/AI/PS/Contour software/Signmaster(optional)
max cutting speed :
1500mm/s
max cutting width :
330mm
auto contour cut :
camera(automatically contour cutting）
control panel :
4.3 inch touch screen
Blade type :
Rowland
max cutting material thickness :
450gsm
connect or interface :
USB cable/Udisk/web cable/WIFI
support system :
all version of windows
max force :
2000g
package details :
wooden case
Description

Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine



The ZKSV350 is an servo cutting plotter, ideal for processing self-adhesive stickers and special-shaped cards/hang tags. It features versatile connectivity options, including USB, Wi-Fi, and Ethernet, for seamless integration into your workflow. With a maximum cutting width of 330mm and a maximum cutting speed of 1500mm/s, this machine delivers reliable performance for your everyday cutting needs.



MODEL ZKSV350
Max. media width 345mm,A4/A3/A3+
Max. cutting width 330mm
Cutting length Unlimited
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor servo motor
Positoning mode Qr code/Dot/Right angle
Number of heads 1
Blade type Rowland blade
Packing size L 780mm*W 580mm*H 520mm
Machine size L 693mm*W 480mm*H 295mm
Gross/Net weight 52kgs/37kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 450gsm
Max. cutting speed 1500mm/s
Max.force 2000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory １Ｇ
Support system All versions of windows



Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine



Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine



Anycut ZKSV350 Advanced Servo Motor A3/A4 Sheet Label Cutting Machine
