Specifications
Brand Name :
Anycut
Model Number :
STD350
Certification :
CE/FCC/RoHS
Place of Origin :
Anhui
MOQ :
1 piece
Price :
$713-917/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1-4 pieces：2days ;5-30 pieces：2-15 days;30-100 pieces:20 days
Delivery Time :
20-30 work days
Packaging Details :
L 790mm*W 510mm*H 450mm
Operation Interface :
4.3-inch color touchscreen, stepper motor control
Cutting system :
Dual-Head Oscillating Blade with Camera Auto-Contour Alignment
Support software :
CDR/AI/PS/Contour software/Signmaster(optional)
Number of heads :
Double-cutter indentation
Media Compatibility :
330 mm max width, supports materials up to 450gsm thickness (cardboard, vinyl)
Cutting Performance :
1000 mm/s speed, ±0.01 mm accuracy, 0.082 mm repeatability
Footprint :
Compact benchtop (700×425×310 mm) with portable design for small spaces
Positioning mode :
QR code/Dot/Right angle
Force & Versatility :
2000g max pressure for cutting + creasing on rigid & flexible substrates
Cutting Application :
Small cards, custom business cards, car dashboard films, vinyl stickers, shaped hang tags, knife board engraving
Software Features :
One-click contour extraction, auto registration points, supports CorelDRAW/AI/PS
Cutting Modes :
Full cut, half cut, creasing, contour cutting
Description

Anycut STD350: Jam-Free Die Cutting Machine with One-Click Contour Extraction



STD350 Double Cutter Head Indentation Die Cutting Machine
—— The All-in-One Cutting Solution for Print Shops, Design Studios & Custom Workshops

✅ Dual Blade Heads for High Efficiency.

Two Roland blade heads work in tandem to complete full cut, half cut, and creasing in one pass, drastically improving production efficiency for small cards, business cards, hang tags, and more.

✅ Large Format & Stable Paper Feeding.

With a maximum media/cutting width of 335mm, it ensures smooth, jam-free paper feeding, easily handling large-format materials like car dashboard films, vinyl stickers, and photo prints.

✅ Smart Positioning & Auto Contour Cutting.

Equipped with a camera-based automatic positioning system and our proprietary software, it can extract contours and generate precise registration points with one click, delivering error-free results for shaped cards, hang tag engraving, and knife board engraving.

✅ Superior Force & Material Compatibility.

A massive 2000g cutting force effortlessly handles 450gsm thick paper, PVC, vinyl, films, and other materials, making it ideal for custom business cards, small cards, tote bags, and diverse applications.

✅ Flexible Connectivity & Intuitive Operation.

Supports USB, USB disk, LAN, and WiFi wireless connections, plus file retrieval via QR code scanning. The 4.3-inch touchscreen ensures intuitive operation, making it easy for beginners to master.

✅ Professional R&D & After-Sales Support.

Our in-house developed hardware and software come with comprehensive technical assistance and a dedicated after-sales team, ensuring stable, reliable performance for long-term production.

Item High speed servo motor label cutting plotter
MODEL ZKSTD350
Max. media width 335mm
Max. cutting width 330mm
Cutting length Unlimited
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor Stepper motor
Positoning mode Qr code/Dot/Right angle
Number of heads 2
Blade type Rowland blade
Packing size L870mm*W 550mm*H 550mm
Machine size L 700mm*W 425mm*H 310mm
Gross/Net weight 40kgs/32kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 450gsm
Max. cutting speed 1000mm/s
Max.force 2000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory 1G
Support system All versions of windows
