Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
Specifications
Brand Name :
Anycut
Model Number :
STD350
Certification :
CE/FCC/RoHS
Place of Origin :
shenzhen
MOQ :
1
Price :
$713~970/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L790mm*W510mm*H450mm
max cutting width :
330mm
auto contour cut :
4.3 inch touch screen
motor :
stepper motor
positioning mode :
Qr code/Dot/Right angle
Blade type :
Rowland
max material thickness :
450gsm
connect or interface :
USB cable/Udisk/web cable/WIFI
support software :
CDR/AI/PS/Contour software/Signmaster
max cutting speed :
1000mm/s
support system :
All version windows
Description

Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine


1. Dual knife head design: Enables indentation and die-cutting to be completed in one pass for efficient processing.

2. High precision cutting: ±0.01mm cutting accuracy and 0.082mm repeatability for precise results.

3. Intelligent positioning: Camera auto-positioning and QR code/file scanning for quick and accurate job setup.

4. Powerful performance: 2000g max force and 450gsm material thickness capacity handle diverse materials easily.

5. Flexible connectivity: WiFi/USB/UDisk/network cable options plus 4.3-inch touch screen for easy operation.

6. Global compatibility: 100-240V adaptive power supply and full Windows system support for worldwide use.

7. Unlimited cutting length: 330mm max cutting width with no length restriction for large-format jobs.



Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine



MODEL ZKSTD350
Max. media width 335mm
Max. cutting width 330mm
Cutting length Unlimited
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor Stepper motor
Positoning mode Qr code/Dot/Right angle
Number of heads 2
Blade type Rowland blade
Packing size L 790mm*W 510mm*H 450mm
Machine size L 700mm*W 425mm*H 310mm
Gross/Net weight 34kgs/29kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 450gsm
Max. cutting speed 1000mm/s
Max.force 2000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory １Ｇ
Support system All versions of windows




Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine



Anycut CCD Camera Contour Double Cutter Head Indentation Die Cutting Machine
