STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera
Specifications
Brand Name :
Anycut
Model Number :
STD350
Certification :
CE/FCC/RoHS
Place of Origin :
shenzhen
MOQ :
1
Price :
$713~970/piece
Payment Terms :
T/T,Western Union
Supply Ability :
1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days
Delivery Time :
20~30 work days
Packaging Details :
L790mm*W510mm*H450mm
max cutting width :
330mm
auto contour cut :
4.3 inch touch screen
motor :
stepper motor
positioning mode :
Qr code/Dot/Right angle
Blade type :
Rowland
max material thickness :
450gsm
connect or interface :
USB cable/Udisk/web cable/WIFI
support software :
CDR/AI/PS/Contour software/Signmaster
max cutting speed :
1000mm/s
support system :
All version windows
cutting accuracy :
+/-0.01mm
repeatability :
0.082mm
Description

STD350 Double-head Self-adhesive Stickers Indentation Die Cutting Machine With CCD Camera


The STD350 is a versatile, high-performance die cutting machine built for precision and efficiency, featuring dual Roland blades that enable both indentation and cutting to be completed in one seamless operation. This eliminates the need for multiple processing steps, making it ideal for producing packaging, business cards, stickers, and premium paper products with crisp, professional results.

Equipped with an intelligent camera positioning system, it supports automatic contour cutting by recognizing QR codes, ensuring accurate alignment and consistent cutting paths for complex, custom designs. The 4.3-inch touchscreen control panel and flexible connectivity (USB, U-disk, WiFi) make it easy to set up and operate, while the 2000g max pressure ensures clean cuts on materials up to 450gsm, including coated paper, PVC, and self-adhesive stickers.

With a max cutting speed of 1000mm/s, ±0.01mm cutting accuracy, and 0.082mm repeatability, it delivers reliable, high-quality output for both small-batch and production-scale jobs. It is compatible with all Windows systems and industry-standard design software like CDR, AI, PS, and Contour software, making it a powerful all-in-one solution for sign shops, print businesses, and packaging manufacturers.



MODEL ZKSTD350
Max. media width 335mm
Max. cutting width 330mm
Cutting length Unlimited
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor Stepper motor
Positoning mode Qr code/Dot/Right angle
Number of heads 2
Blade type Rowland blade
Packing size L 790mm*W 510mm*H 450mm
Machine size L 700mm*W 425mm*H 310mm
Gross/Net weight 34kgs/29kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 450gsm
Max. cutting speed 1000mm/s
Max.force 2000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory １Ｇ
Support system All versions of windows
