Specifications
Place of Origin :
Jiangsu, China
Brand Name :
HENTG Power
Model Number :
ZGS Series
Price :
CN¥62,678-124,643.75/sets
Certification :
CE
Frequency :
50Hz
Coil Number :
Multi Winding, Three Windings, Two Windings
application :
distribution system
Coil Structure :
Shell-Type Coil, Disc Coil, fully sealed construction
Output Voltage :
110V, 220V, 380V, 400V , 440V, 480V
Input Voltage :
11kV, 10.5kV, 3kV, 12.47kV, 6.6kV, 6kV, 10kV, 35kV
Type :
Oil-Immersed Transformer, Loop feed/ Radial feed
Efficiency :
>99%
Name :
Oil Type Three Phase Pad Mounted Transformer
Primary voltage :
2.4 through 35KV (150KV BIL)
Low Voltage :
Up to 600 volts
Customized :
Accept
Capacity :
3150-3750 kVA
Warranty :
3 years
Feed Type :
Loop Feed
Connection Group :
DYN1
Enclosure Rating :
NEMA 3R
Application :
Data center,Utility,New energy
Mounting :
Pad-Mounted
Impedance :
4.5%
Sound Level :
65dBA
Winding Material :
Copper or Aluminum
Efficienc :
99.00%
MOQ :
2 sets
Description


High-Capacity Panel Electrical Equipment for Power Substation 3750kva Theree-Phase Pad Mounted Transformer

VR
High Capacity Theree Phase Pad Mounted Transformer 3750kva 50Hz For Power Substation
PRODUCT PARAMENTERS
High Capacity Theree Phase Pad Mounted Transformer 3750kva 50Hz For Power Substation
THREE PHASE PAD MOUNTED TRANSFORMER







Capacity (KVA)
HV
Tapping range
LV
No-load loss
Load loss
lmpedance
Efficiency
75


2400
4160
7200
7620
12000
12470
13200
13800
14400
19920
24940
34500




±2X2.5%


110
120
208
240
277
347
415
416
480
600
690
130
100
4.0-6.3
99.03
152



200
1800

99.16
225



350
3100

99.23
300



430
3700

99.27
500



600
5410

99.35
750



880
7500

99.4
1000



1000
10300

99.43
1500



1400
14500

99.48
2000



1800
18300

99.51
2500



2300
23100

99.53
3150







3750







High Capacity Theree Phase Pad Mounted Transformer 3750kva 50Hz For Power Substation


  • Feature:​
    This 3750kVA three-phase pad-mounted transformer adopts advanced cold-rolled silicon steel lamination core technology, ensuring excellent magnetic permeability and low hysteresis loss. The winding material is high-quality aluminum. Compared with copper, aluminum windings have higher resistivity, effectively reducing eddy current losses and improving overall performance. It has a primary voltage of three-phase 12470 delta and a secondary voltage of three-phase 600Y/347 grounded, capable of adapting to various complex power environments. Equipped with a standard NEMA type 3R enclosure, it can easily handle both indoor and outdoor application scenarios.​
    Advantage:​
    The robust structural design enables it to withstand harsh weather and external forces, ensuring the long-term stable operation of the equipment. The characteristics of low operating costs and low heat dissipation not only reduce energy consumption but also lower the investment and maintenance costs of cooling equipment. The aluminum winding material, while improving performance, reduces the weight of the transformer, simplifies transportation and installation, and effectively controls costs.​
    Benefit:​
    For users, this transformer can provide significant energy savings, helping users reduce electricity bills and operating costs. At the same time, its efficient and stable performance extends the service life of the equipment, reducing the frequency of equipment replacement and maintenance, and further saving the total cost of ownership. Whether in industrial sites, commercial buildings, or public facilities, they can all benefit from the efficient operation of this transformer, ensuring the reliability and stability of power supply.
