1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
Specifications
Place of Origin :
Hunan, China
Brand Name :
HENTG Power
Model Number :
ZGS
Certification :
CE
Price :
CN¥288160/pieces
Type :
distribution transformer, power transformer, Oil-filled Transformer
Frequency :
50Hz, 60Hz
Winding Material :
Aluminum
application :
Power
Phase :
Three
Coil Structure :
TOROIDAL
Coil Number :
Multi-winding coil
Input Voltage :
10kV
Output Voltage :
277V, 480V
Product name :
Toroidal Transformer
Material :
Aluminum Winding
Application :
Power Distribution System
Usage :
Power Electronic
Transformer type :
Toriodal Transformer
Name :
High Fequency Transformer
Feature :
High Efficiency
Insulation Class :
Class A
Standard :
ANSI,IEC
Voltage Class :
15 kV to 35 kV
Impedance Voltage :
5.8%
Primary Voltage :
8320V
Feed Type :
loop feed
Enclosure Material :
Steel or Aluminum
Cooling Type :
ONAN/KNAN
Insulation Level :
E Class
MOQ :
2 sets
Description
1500kVA Three-Phase Pad-Mounted Transformer | Outdoor Oil-Immersed Power Solution for Industrial & Utility Use
PRODUCT PARAMENTERS
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design
THREE PHASE PAD MOUNTED TRANSFORMER







Capacity (KVA)
HV
Tapping range
LV
No-load loss
Load loss
lmpedance
Efficiency
75


2400
4160
7200
7620
12000
12470
13200
13800
14400
19920
24940
34500




±2X2.5%


110
120
208
240
277
347
415
416
480
600
690
130
100
4.0-6.3
99.03
152



200
1800

99.16
225



350
3100

99.23
300



430
3700

99.27
500



600
5410

99.35
750



880
7500

99.4
1000



1000
10300

99.43
1500



1400
14500

99.48
2000



1800
18300

99.51
2500



2300
23100

99.53
3150







3750







1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design



We have a professional team to guide the installation, and also support on-site installation. We will provide
you with more than 2 years of warranty service. Welcome to join us and create a win-win situation. Click here to start our
business now.
If you have any questions, welcome to click here for discussion !!!
WHY CHOOSE US
1500kVA Industrial Three Phase Pad Mounted Transformer Tamper Resistant Design

Product Overview:

The 1500kVA Three-Phase Pad-Mounted Transformer is an advanced, high-capacity power distribution solution designed for outdoor environments. With a sealed, oil-immersed cooling system, tamper-resistant design, and robust construction, this transformer delivers reliable performance and safety for mission-critical electrical systems. It's optimized for utility companies, large-scale industries, and commercial power networks requiring efficient, long-term energy management.

F – Features

  • Pad-mounted three-phase configuration

  • Oil-immersed self-cooled system

  • Tamper-proof, weather-resistant enclosure

  • Low-noise and vibration operation

  • Durable, maintenance-minimized design

  • International compliance (IEEE, ANSI, IEC)

B – Benefits

  • ✅ High Power Capacity: Handles large electrical loads with stability and precision, ideal for high-demand environments.

  • ✅ Built for Outdoors: Enclosure is engineered to withstand harsh weather, temperature extremes, and vandalism.

  • ✅ Reduced Maintenance Needs: Oil-immersed cooling and sealed tank reduce the need for regular maintenance.

  • ✅ Space-Saving Installation: Pad-mounted design simplifies site preparation and reduces installation footprint.

  • ✅ Reliable Safety: Integrated protections and a sealed structure guard against faults and external risks.

  • ✅ Operational Efficiency: Designed to minimize energy loss and maximize performance across years of use.

  • ✅ Versatile Compatibility: Suitable for integration into diverse power distribution systems, from substations to industrial grids.

A – Applications

Typical Applications:

  • Utility Substations: Delivers consistent voltage transformation and backup support.

  • Manufacturing & Processing Plants: Powers large machinery, conveyors, and automation systems.

  • Renewable Energy Projects: Converts and distributes electricity from solar or wind power sources.

  • Large Commercial Complexes: Ideal for shopping centers, office parks, and mixed-use developments.

  • Institutional Campuses: Serves hospitals, universities, and airports with safe, scalable power supply.


BUSINESS PARTNER
Q: Who are we ?
HENTG POWER is a professional designer, manufacturer and installer of power system solution around the World, was
founded in 2011, occupies 100,000 square meter. specializing in reliable, high-performance solutions for global power systems
Q:How can we guarantee quality ?
Always a pre-production sample before mass production; Always final Inspection before shipment, We
will provide QC & test reports. We accept FAT(Factory Acceptance Test). Factory can manufacture oil type and dry type
distributiontransformer, max 500KV 480MVA power transformer, GIS, switchgear, substation, based on ANSI/IEEE/DOE2016/CSA/IEC60076 standard. We will provide you with the guarantee service of over 2 years.
Q: Why choose us?
We have the professional and independent drawing team and technical team, It is expected that we can confirm all the contents on the drawings with you within 7 days. we have a professional technical team with 30+ senior engineers offer 24 hours online service and response within 30 min.
Q: What servicescan we provide ?
Accept OEM, business payment are negotiated.
