ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
ASME Vacuum Distillation Equipment Stainless Steel 5-5500kg/H
Specifications
Supply Ability :
6000sets/Year
Model Number :
WFE/SPD/BEM/BES/AES/BEU/TFE
Style :
Steel Type
Certification :
ASME U/ISO9001/ ISO45001/ ISO14001/PED/CE/CRTU/DOSH
Material :
Stainless Steel
MOQ :
1 Set
Delivery Time :
45-60 working days
Size :
Customzied
Payment Terms :
T/T,L/C
Price :
Negotiation
Usage :
Pharmaceutical, Fine Chemical, Food & Beverage, Biotechnology, New Energy Materials etc
Place of Origin :
Jiangsu China
MOQ :
1set
Packaging Details :
Steel saddle+LDPE foil+Tarpaulin/Wooden box
Brand Name :
Yiteng
Application :
Thin Film Evaporator, TFE/pharmaceutical distillation equipment/API purification distillation
Description
Product Description
Our ASME U Stamp Distillation Equipment is designed and manufactured in full compliance with ASME BPVC Section VIII standards. All pressure-containing parts undergo strict inspection and certification to guarantee safe and stable thermal separation under vacuum and high-temperature conditions. Widely used in fine chemicals and environmental protection sectors, this ASME Vacuum Distillation Equipment satisfies stringent international quality requirements for continuous industrial separation processes.
We deliver tailored process solutions covering different technical routes. Precision purification can be achieved through ASME U Stamp Certified Distillation for high-purity fractionation tasks with our Stainless Steel Short Path Evaporator. To process heat-sensitive materials without deterioration, our Continuous Thin Film Evaporation System paired with Continuous Molecular Distillation offers efficient low-temperature evaporation with short residence time. For cost reduction and circular production, our Industrial Vacuum Solvent Recovery Equipment efficiently recycles organic solvents from industrial wastewater and waste streams.
Product parameter
Parameter Typical Value/Range Remarks
Evaporation Capacity 5～5500 kg/h Evaporation efficiency depends on material properties and heat transfer temperature difference
Operating Pressure 1atm～1mbar High vacuum working conditions require matching vacuum units
Operating Temperature 50-300°C High-temperature series with maximum operating temperature up to 350°C
Heat Transfer Area 0.1-100m² Custom designs available for the full range
Wiper Speed 2-15 m/s Affects liquid film thickness and heat transfer efficiency
Motor Power 0.25-55kw Correlates positively with rotor diameter and material viscosity
Viscosity Range 1-100000cP Specialized wiper design required for high-viscosity materials
Wiper Type Structural Features Material & Temp. Clearance/Film Application Scenarios Viscosity Limit Industry
Hinged Wiper Spring-loaded, self-adapting to wall wear PTFE ≤150°C
Enhance PTFE ≤200°C
CF-PTFE ≤250°C
polybenzoate‌ ≤280°C
Copper≤300°C
304 ≤300°C
316L ≤400°C		 General purpose 20,000 cP Glycerol, tire additives, inorganic salts, sugar alcohols, fermentation broth, solvent recovery, waste oil regeneration, high-salinity wastewater, etc.
Sliding Wiper Graphite/PTFE bushings, hydraulic assist / High-precision film control 50,000 cP Vitamins, antibiotics, resins, plant extracts, etc.
Fixed Wiper Rigid connection, no moving parts / Ultra-high viscosity (polymer melts) 100,000 cP food additives, fruit juices, dairy products, etc.
Roller Wiper Equipped with rollers, reducing friction / Materials with solid particles 30,000 cP Foods, polymer resins, syrups, asphalt, rubber liquid, etc.
Wiper Type Structural Features Material & Temp. Clearance/Film Application Scenarios Viscosity Limit Industry
Hinged Wiper Spring-loaded, self-adapting to wall wear PTFE ≤150°C
Enhance PTFE ≤200°C
CF-PTFE ≤250°C
polybenzoate‌ ≤280°C
Copper≤300°C
304 ≤300°C
316L ≤400°C		 General purpose 20,000 cP Glycerol, tire additives, inorganic salts, sugar alcohols, fermentation broth, solvent recovery, waste oil regeneration, high-salinity wastewater, etc.
Sliding Wiper Graphite/PTFE bushings, hydraulic assist / High-precision film control 50,000 cP Vitamins, antibiotics, resins, plant extracts, etc.
Fixed Wiper Rigid connection, no moving parts / Ultra-high viscosity (polymer melts) 100,000 cP food additives, fruit juices, dairy products, etc.
Roller Wiper Equipped with rollers, reducing friction / Materials with solid particles 30,000 cP Foods, polymer resins, syrups, asphalt, rubber liquid, etc.

Why Partner With Us?

· 1:1 Drawing Optimization: Our engineering team reviews and optimizes your blueprints to reduce production costs.

· Reliable Lead Time: Streamlined manufacturing process ensures your project timeline is protected.

· Global Shipping Experience: Full support for sea freight, customs clearance, and documentation.

Let's discuss your next project!
