2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
Specifications
Model Number :
PMPLC-141550PS0905-2M(2Group
Packaging Details :
100×80×10mm
Place of Origin :
Guangdong , China
Brand Name :
Gracyfiber
Certification :
ISO9001 , ROHS
MOQ :
1pieces
Payment Terms :
L/C,T/T
Delivery Time :
5-8 work days
Supply Ability :
100,000 pieces per month
Name :
Polarization Maintaining PLC Splitter
Insertion Loss :
≤ 8.2 dB
Channel Uniformity :
≤ 0.8 dB
Extinction Ratio :
≥ 18 dB
Return Loss :
≥ 50 dB
Operating Wavelength :
1260 -1650 nm
Module Size :
100 * 80 * 10 mm
Description

2x(1x4) PM PLC Splitter Polarization Maintaining Fiber Splitter 1260 1650nm FC APC To MPO APC For Coherent Communication Gyroscope And Fiber Sensor

1. Product Overview

This product is a 2*(1*4) PM PLC Splitter (two sets of 1*4 polarization-maintaining PLC splitters), integrating two independent 1*4 polarization-maintaining splitter channels within a single module.

2. Product Advantages

  • Dual-Group 1*4 Integration, Eight Outputs in One Module


  • Low Insertion Loss and Excellent Channel Uniformity


  • High Extinction Ratio, Strong Polarization Preservation Capability

  • High Return Loss and High Directivity, Reducing Reflection and Crosstalk


  • Wide Operating Wavelength and Environmental Adaptability


  • Compact Structure and Clear Cabling


3. Product Features (Key Features)
Parameters Unit Value
Operating Wavelength nm 1260~1650
Test Wavelength nm 1550
Insertion Loss dB ≤8.2
Uniformity dB ≤0.8
Extinction Ratio dB ≥18
Return Loss dB ≥50


4. Applications
  • Coherent Communication
  • Fiber Optic Gyroscope
  • Fiber Sensor


2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm

2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm

2x4 1x4 Polarization Maintaining PLC Splitter , PM Fiber Splitter 1260nm 1650nm
