Specifications
Place of Origin :
Guangdong , China
Brand Name :
Gracyfiber
Certification :
ISO9001 , ROHS
Delivery Time :
5-8 work days
Payment Terms :
L/C,T/T
Supply Ability :
100,000 pieces per month
MOQ :
1pieces
Operating Wavelength :
1260~1650 nm
Insertion Loss :
≤8.2 dB
Extinction Ratio :
≥18 dB
Return Loss :
≥50 dB
Power Handling :
300 mW
Operating Temperature :
-5~+65 ℃
Description

1. Specifications

Parameters

Unit

Value

Operating Wavelength

nm

1260~1650

Test Wavelength

nm

1550

Insertion Loss

dB

≤8.2

Uniformity

dB

≤0.8

Extinction Ratio

dB

≥18

Return Loss

dB

≥50

Directionality

dB

≥50

Pigtail

/

Input:0.9m blue hytrel tube

Output:3.0mm yellow PVC Tube

Input & Output Length

m

0.5±0.03

Connector

/

Input=FC/APC(slow axis work),

Output=MPO/APC(male)-(Fast axis work)

Fiber Mark

/

Numbering tube

Package Dimension

mm

100*80*10

Power

mW

300

Operating Temperature

℃

-5~+65

Storage Temperature

℃

-40～+85

Fiber Type

/

PM 15-U25D

2．Package Dimension

2Group 1x4 PM PLC Splitter 1260-1650nm High Extinction Ratio Low Insertion Loss ABS Box 100x80x10mm FC/APC to MPO/APC Polarization Maintaining Module Custom



2Group 1x4 PM PLC Splitter 1260-1650nm High Extinction Ratio Low Insertion Loss ABS Box 100x80x10mm FC/APC to MPO/APC Polarization Maintaining Module Custom2Group 1x4 PM PLC Splitter 1260-1650nm High Extinction Ratio Low Insertion Loss ABS Box 100x80x10mm FC/APC to MPO/APC Polarization Maintaining Module Custom

3. Ordering information

PMPLC

-

XXX

XXX

XX

XX

XX

-

X

X



Port NO

Wavelength

Modules type

Fiber Type

Fiber Length


Input

connector

Output

Connector

PM PLC

　

14=1X4

131=1310nm

PS=100 X80 X10

02=250um fiber

05=0.5m


0=None

0=None

　


148=1480nm

XX=Customized

09=0.9mm Tube

XX=Customized


1=FC/UPC

1=FC/UPC

　


155=1550nm


20=2.0mm Tube



2=FC/APC

2=FC/APC

　

　


980=980nm


30=3.0mm Tube



3=SC/UPC

3=SC/UPC

　

　


106=1064nm


XX=Customized



4=SC/APC

4=SC/APC

　

　


780=780nm





5=LC/UPC

5=LC/UPC

　

　



　




6=LC/APC

6=LC/APC

　

　



　




X=Customized

M=MPO

Part Number

Product Description

PMPLC-141550PS0905-2M(2Group)

2Group 1*4 PM PLC Splitting, PM15-U25D fiber,input with 0.9mm Hytrel Blue Tube FC/APC, Output with 3.0mm PVC Tube ,MPO/APC connector.

ABS BOX: 100*80*10mm.


Applications
Coherent optical communication systems
High-precision fiber optic sensor networks
Fiber optic gyroscope (FOG) systems
LiDAR signal distribution
Polarization-maintaining optical testing and measurement instruments
High-order optical module integration such as erbium-doped fiber amplifiers (EDFAs)



FAQ

1. What is the operating temperature range and power consumption of this splitter? Can the ABS box packaging adapt to the complex environment of a data center?
As a purely passive optical device, this device has a power consumption of 0W. It uses a high-strength, pressure-resistant ABS plastic black box (100x80x10mm) for packaging, ensuring neat cable management. The internal optical waveguide chip and polarization-maintaining array employ a high-reliability sealing and curing process. The product supports industrial-grade wide-temperature operation from -40°C to +85°C, unaffected by the extreme temperature differences of outdoor sensing nodes or the high heat loads of data center environments.

2. Do you support specific polarization axis alignment methods, special wavelengths, or custom interfaces (OEM/ODM)?
Fully supported. As a source manufacturer of polarization-maintaining devices, we provide in-depth non-standard customization services. You can precisely specify slow axis alignment (default) or fast axis alignment; for connectors, high-precision FC/APC, LC/APC and other connectors with narrow keys can be customized; the length of the optical fiber and the outer sheath diameter (such as 0.9mm / 2.0mm) can be strictly sampled and mass-produced according to your engineering drawings.
