Two Component Glue Spraying Equipment Fully Automatic 100 - 1300mm Coating Width
Two Component Glue Spraying Equipment Fully Automatic 100 - 1300mm Coating Width
Specifications
Brand Name :
LONGYU
Model Number :
LY-02-1300
Certification :
ISO9001
MOQ :
1SET
Price :
USD:20000.00-40000.00
Payment Terms :
T/T
Supply Ability :
1000Sets/Years
Delivery Time :
30-60 days
Packaging Details :
Standard wooden case
Adhesive System :
Two-Component (2K)
Primary Use :
Honeycomb & SPC Panel Bonding
Mixing Accuracy :
High Precision
Control Feature :
Auto Width Recognition (Optional)
After-sales service provided :
Engineers available to service machinery overseas,Video technical support,Free spare parts,Online support,Field installation
Warranty :
1 Year,12 Months,One year since the date B/L
Color :
customized,Blue,Company Standar
Function :
Forming,Spring Coil Making Machine,Spring coiling machine
Description

Fully Automatic Two-Component Glue Spraying Equipment

Specifications:

Technical Parameter

Specification

Model Number

LY-02-1300

Work Coating Amount

500 - 4000 g/min

Adhesive Flow Accuracy

≤ ±5%

Glue Nozzle Hole Interval

8mm

Coating Width Range

100 - 1300 mm (Auto-recognition Optional)

Max. Production Line Speed

15 m/min

Glue Application (Unit Area)

120 - 400 g/m² (Total ≤ 4000 g/min)

Adhesive Viscosity Range

Up to 25,000 mPa.s

Adhesive Type

Two-Component

Equipment Length (Standard)

10 m (Customizable)

Air Supply

0.6 - 0.8 MPa

Power Supply

380V, 50Hz, 3-Phase (Optional)

Max. Power

10 KW

Two Component Glue Spraying Equipment Fully Automatic 100 - 1300mm Coating Width

Two Component Glue Spraying Equipment Fully Automatic 100 - 1300mm Coating Width

Two Component Glue Spraying Equipment Fully Automatic 100 - 1300mm Coating WidthTwo Component Glue Spraying Equipment Fully Automatic 100 - 1300mm Coating Width

Applications:
Ideal for the lamination process in the production of:

1. Honeycomb Panels (e.g, for doors, partitions)

2. SPC (Stone Plastic Composite) Panels

3. Door and Automotive Interior Panels

4. Building Insulation Wall Panels

5. Other composite panel structures requiring high-strength bonds.

Two Component Glue Spraying Equipment Fully Automatic 100 - 1300mm Coating Width

Quick Detail:

1. Dual-Component System: Designed for precision metering and mixing of two-component adhesives.

2. High-Speed Curtain Coating: Work coating capacity from 500 to 4000 g/min.

3. Excellent Accuracy: Adhesive flow accuracy within ±5%.

4. Wide & Adaptive: Coating width range 100-1300mm (optional auto-width recognition).

5. For Rigid Panels: Ideal for honeycomb, SPC composite, door, and automotive panels.

6. Powerful & Customizable: Standard length 10m (customizable), robust 10KW power system.
