0.85mm RAL7012 PPGI Color Coated Galvanized Steel Coil with 180g/m² Zinc Coating for Flange Plate and Building Panels

１．Product Overview

0.85mm RAL7012 PPGI Color Coated Galvanized Steel Coil is a pre-painted steel coil designed for flange plate, building panels, roofing components, vehicle manufacturing, furniture, and electric industry applications.

The product uses SGCC, CGCC, or DX51D+Z substrate with 180g/m² zinc coating and polyester paint system. The 1250mm width supports building panel production and general sheet fabrication, while the pre-painted surface reduces secondary coating work during downstream processing.

２．Technical Solution

The galvanized steel substrate provides corrosion protection through 180g/m² zinc coating. The top surface uses 10μm polyester coating plus 5μm primer to improve color appearance and paint adhesion.

The back surface uses 7μm coating plus 5μm primer to improve reverse-side protection during storage, transportation, forming, and installation.

The available substrate and coating options include Z20–Z275 and AZ30–AZ150, allowing different corrosion protection levels for construction and industrial applications.

３．Specifications

４．Application

• Flange plates
• Roofing sheets
• Steel structure workshop panels
• Airport and warehouse roofing panels
• Shipbuilding components
• Vehicle manufacturing parts
• Furniture panels
• Electric industry panels
• Building wall panels
• General color coated sheet fabrication

５．Processing

• Roll forming
• Cut-to-length processing
• Slitting
• Bending
• Profiling
• Roofing sheet production
• Wall panel fabrication
• Flange plate processing
• Decorative panel forming

６．Advantages

• 180g/m² zinc coating supports corrosion resistance for construction and industrial applications.
• 0.85mm thickness provides better rigidity than thinner decorative coils.
• 1250mm width supports efficient panel and sheet processing.
• Top polyester coating plus primer improves appearance and coating adhesion.
• Back coating plus primer improves reverse-side protection during handling and installation.
• RAL color system supports project color consistency.
• Three-layer packing supports coil protection during export transportation.

７．How to Choose

• Select 0.85mm thickness when higher panel rigidity is required.
• Confirm 1250mm width compatibility with roll forming or sheet processing equipment.
• Choose zinc coating level according to outdoor exposure and corrosion risk.
• Confirm RAL color before production to maintain color consistency.
• For flange plate processing, verify forming method and coating adhesion requirements.

８．FAQ

Q1．What is the specified zinc coating?

The specified zinc coating is 180g/m².

Q2．What is the specified thickness and width?

The specified thickness is 0.85mm and the specified width is 1250mm.

Q3．What color is supplied?

The specified color is RAL7012, with other RAL standard colors available according to requirement.

Q4．What top coating structure is used?

The top surface uses 10μm polyester coating plus 5μm primer.

Q5．What applications are suitable for this product?

It is suitable for flange plates, roofing sheets, building panels, vehicle parts, furniture panels, and electric industry components.
