0.19mm RAL9010 Pre Coated Galvanized Steel Coil with 90g/m² Zinc Coating for Roofing and Building Panels

１．Product Overview

0.19mm RAL9010 Pre Coated Galvanized Steel Coil is a color coated steel material designed for roofing sheets, wall panels, building components, vehicle parts, shipbuilding components, furniture panels, and electrical equipment applications.

The product uses galvanized or galvalume steel substrate with PE paint coating and primer system. The 90g/m² zinc coating supports corrosion protection, while the pre-painted surface provides decorative appearance and processing convenience for light-gauge building panel applications.

２．Technical Solution

The steel substrate is protected by 90g/m² zinc coating and then coated with a polyester paint system. The top surface uses 10μm polyester coating plus 5μm primer to improve surface appearance and adhesion.

The back surface uses 5–7μm primer to provide reverse-side protection during coil storage, transportation, forming, and installation. The pre-painted finish can reduce secondary painting work during downstream fabrication.

Soft commercial quality or lock forming quality can be selected according to forming and processing requirements.

３．Specifications

４．Application

• Roofing sheets for steel structure workshops
• Airport and warehouse roofing panels
• Building wall panels
• Vehicle components
• Shipbuilding components
• Furniture panels
• Electrical household appliances
• Mechanical and electrical equipment
• Decorative color coated sheets
• Light-gauge construction panels

５．Processing

• Roll forming
• Roofing sheet production
• Wall panel fabrication
• Cut-to-length processing
• Slitting
• Bending
• Lock forming
• Protective film application
• Decorative sheet processing

６．Advantages

• 90g/m² zinc coating provides corrosion protection for light-gauge building applications.
• 10μm polyester top coating plus primer supports surface appearance and adhesion.
• 5–7μm back primer improves reverse-side protection during storage and forming.
• 0.19mm thickness is suitable for lightweight roofing and decorative panel production.
• 900mm width supports narrow panel fabrication and customized processing.
• PE paint system provides a practical coating solution for general building use.
• Protective film option helps reduce surface scratches during processing.

７．How to Choose

• Select 0.19mm thickness for lightweight decorative or formed panel applications.
• Confirm 900mm width compatibility with roofing or panel production equipment.
• Use PE coating for general construction and indoor/outdoor building applications.
• For applications requiring surface protection during forming, choose protective film on the top side.
• Confirm RAL color before production to maintain project color consistency.

８．FAQ

Q1．What is the specified thickness of this product?

The specified thickness is 0.19mm.

Q2．What is the specified width?

The specified width is 900mm.

Q3．What is the zinc coating level?

The zinc coating is 90g/m².

Q4．What paint system is used?

The paint type is PE, with 10μm polyester plus 5μm primer on the top surface.

Q5．What applications are suitable for this coil?

It is suitable for roofing sheets, wall panels, vehicle components, shipbuilding components, furniture panels, and electrical household appliances.
