700–1250mm Pre Painted PVDF Steel Coil with 30–275g/m² Zinc Coating for Industrial Roofing and Wall Cladding

１．Product Overview

Pre Painted Steel Coil is a color coated steel material used for industrial roofing, wall cladding, exterior panels, manufacturing components, and building envelope systems.

This product uses zinc coated steel as the substrate and applies PE, SMP, HDP, or PVDF paint coating to improve surface durability, corrosion resistance, and color appearance. With 700–1250mm width, 3–8MT coil weight, and 508 / 610mm coil ID, it is suitable for continuous roll forming, profiling, slitting, and panel fabrication.

２．Technical Solution

The product is produced through pre-painted coil coating technology. Zinc coating from 30–275g/m² provides corrosion protection for the steel substrate, while the paint coating improves weather resistance, UV resistance, and surface stability.

The 10–25μm top coating provides exposed-side protection and appearance control. The 5–7μm back coating improves reverse-side protection during transportation, storage, forming, and installation.

PVDF coating is suitable for industrial and outdoor applications requiring stronger weather resistance. PE, SMP, and HDP coatings can also be selected according to different application environments and durability requirements.

３．Specifications

４．Application

• Industrial roofing sheets
• Wall cladding panels
• Building exterior panels
• Steel structure enclosure systems
• Factory and warehouse panels
• Architectural decorative panels
• Industrial manufacturing components
• Outdoor metal panels
• Interior and exterior decoration
• General roll formed building materials

５．Processing

• Roll forming
• Slitting
• Cut-to-length processing
• Bending
• Profiling
• Panel fabrication
• Protective film application
• Roofing sheet production
• Wall panel forming
• Industrial sheet processing

６．Advantages

• 30–275g/m² zinc coating supports corrosion resistance for industrial and outdoor environments.
• 10–25μm top coating improves weather resistance, color stability, and surface protection.
• 5–7μm back coating improves reverse-side protection during processing and installation.
• PE, SMP, HDP, and PVDF paint coatings support different durability and exposure requirements.
• 700–1250mm width range supports roofing sheet, wall panel, and industrial fabrication applications.
• 508 / 610mm coil ID supports compatibility with standard decoiling and forming equipment.
• 900–1500mm coil OD supports coil handling and continuous production requirements.

７．How to Choose

• For general industrial panels, PE coating can be selected.
• For exterior wall cladding and roofing sheets, SMP or HDP coating is suitable for improved weather resistance.
• For high UV exposure, coastal areas, or long-term outdoor use, PVDF coating is recommended.
• For humid or corrosive environments, select a higher zinc coating level.
• For production line compatibility, confirm width, coil weight, coil ID, and coil OD before ordering.

８．FAQ

Q1．What zinc coating range is available

The zinc coating range is 30–275g/m².

Q2．What paint coating systems are available

PE, SMP, HDP, and PVDF paint coating systems are available.

Q3．What is the top coating thickness

The top coating thickness is 10–25μm.

Q4．What is the back coating thickness

The back coating thickness is 5–7μm.

Q5．What coil IDs are available

508mm and 610mm coil IDs are available.

Q6．What applications are suitable for this product

It is suitable for industrial roofing, wall cladding, building panels, exterior decoration, steel structure enclosures, and general industrial fabrication.
