Specifications
Tap-density :
≥1.50 g/cm³
D50(μm) :
5.14
MOQ :
1kg
Delivery Time :
10 working days
Apparent density :
≥0.60 g/cm³
Appearance :
Black
Price :
110-115USD
D90(μm) :
10.02
Packaging Details :
Carton Packaging
Li :
7.40±0.20 wt%
Model Number :
NMC622 GN-S76L
SSA :
0.70±0.25 m²/g
Micro Shape :
Ball shape
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
D10(μm) :
2.56
Crystal structure :
without impurity
Supply Ability :
500 kgs/month
Co+Ni+Mn :
56.00-62.00 wt%
Brand Name :
Gelon
PH :
11.30±0.30
Certification :
CE
H2O :
≤0.0500 wt%
Place of Origin :
China
Description
Single Crystal NMC622 S76L LiNi0.6Co0.2Mn0.2O2 Cathode Powder

Single crystal NMC622 S76L cathode powder specifically developed for university labs, research institutes, and lithium battery electrode manufacturers.

Contact for details:
Email: Kimberley@libgroup.net
WhatsApp/Mobile/Wechat: +86-13686664348
Product Overview

Single crystal NMC622 S76L (LiNi0.6Co0.2Mn0.2O2) is a high-performance single crystal ternary cathode material engineered for advanced lithium battery research and manufacturing applications.

Chemical Composition Analysis
Parameter Measured Value Standard Range
Total Ni+Co+Mn 60.30 wt% 56.00-62.00 wt%
Li Content 7.37 wt% 7.40±0.20 wt%
pH Value 11.08 -
Moisture Content 0.0176 wt% -
Impurity Control
  • Fe: 0.0015 wt%
  • Cu: 0.0005 wt%
  • Ca: 0.0035 wt%
  • Na: 0.0188 wt%
  • Zn: 0.0002 wt%
Physical Performance
  • Tapped Density: 2.10 g/cm³
  • Apparent Density: 0.91 g/cm³
  • Specific Surface Area: 0.74 m²/g
  • Particle Size: D10=2.56μm, D50=5.14μm, D90=10.02μm
  • Spherical single crystal particles without impurity crystal phase
  • Black uniform powder verified by XRD & SEM analysis
Electrochemical Performance
Test Condition Performance
0.1C Discharge Capacity ≥163 mAh/g
0.5C Discharge Capacity ≥155 mAh/g
1C Discharge Capacity ≥153 mAh/g
0.1C Initial Coulombic Efficiency 88.2%
Median Voltage 3.64V
Internal Resistance ≤33.0 mΩ
Cycle Performance & Stability
  • 100 cycles: 98% capacity retention
  • 200 cycles: 96.5% capacity retention
  • 300 cycles: 94% capacity retention
  • Excellent high & room temperature storage performance
  • Low inflation rate during cycling
Application & Process Guidelines

Compatible with both artificial graphite and natural graphite systems.

Recommended Formula Ratio
  • Active Material: 94.5%
  • Super P: 2%
  • KS6: 1%
  • HSV900: 2.5%
Processing Parameters
  • Suggested Compaction Density: 3.50-3.55 g/cm³
  • Maximum Compaction: ≥3.60 g/cm³
Applications
  • Academic electrochemistry experiments
  • Electrode formula development
  • Prismatic/coin cell prototype testing
  • High-capacity lithium battery mass production

Each production batch includes comprehensive material characterization with XRD, SEM, PSD analysis, and complete electrical cycle test reports.
