GN-CC20E Electric Coin Cell Crimping Machine Corrosion-Resistant Steel For CR2032/CR2025/CR2016 Glove Box Use
GN-CC20E Electric Coin Cell Crimping Machine Corrosion-Resistant Steel For CR2032/CR2025/CR2016 Glove Box Use
GN-CC20E Electric Coin Cell Crimping Machine Corrosion-Resistant Steel For CR2032/CR2025/CR2016 Glove Box Use
GN-CC20E Electric Coin Cell Crimping Machine Corrosion-Resistant Steel For CR2032/CR2025/CR2016 Glove Box Use
GN-CC20E Electric Coin Cell Crimping Machine Corrosion-Resistant Steel For CR2032/CR2025/CR2016 Glove Box Use
GN-CC20E Electric Coin Cell Crimping Machine Corrosion-Resistant Steel For CR2032/CR2025/CR2016 Glove Box Use
Specifications
Power Supply :
AC220V/50Hz， 110V/60Hz
Net Weight :
≈28kg
Power :
200W
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
MOQ :
1
Certification :
CE
Crimping Efficiency :
60 seconds/piece
Model Number :
GN-CC20E
Size after Packaging :
≈L500*W340*H820mm
Warranty Period :
1-year warranty, lifetime maintenance
Brand Name :
Gelon
Equipment Dimensions :
≈L334*W257*H479mm
Price :
1999-2199 USD
Supply Ability :
500 sets/month
Crimping Die :
CR2032 is standard
Dismantling Die :
CR2032 is standard
Place of Origin :
China
Crimping Stroke :
About 30mm
Delivery Time :
25-35 days
Packaging Details :
Wooden case
Gross Weight :
≈33kg
Description

GN-CC20E Electric Coin Cell Crimping Machine

GN-CC20E Electric Coin Cell Crimping Machine Corrosion-Resistant Steel For CR2032/CR2025/CR2016 Glove Box Use



Contact for details

Email: Kimberley@libgroup.net

WhatsApp/Mobile/Wechat: +86-13686664348


Products Description

1. Overview

This equipment is mainly used for crimping and disassembling coin cells. Only one type (sealing/disassembling) die can be selected as standard for this equipment.

Mainly driven by an electric motor, after placing the battery into the die, pressing the motor button will cause the upper and lower dies to automatically close, crimping and forming the battery. It is used for sample preparation in laboratory battery material research and development, for making coin cells and sealing capacitors, and can also be used for small batch trial production in factories.


2. Features

1. Touchscreen operation makes it easy to set parameters and has a high degree of automation.

2. Electric-driven, vibration-free battery sealing, and no leakage.

3. With different dies, it can crimp and disassemble various specifications of coin cells, achieving multi-purpose use with a single machine.

4. Precise die design ensures accurate and reliable crimping and forming, with stable and safe use.

5. Aesthetically pleasing in appearance, easy to maintain, with the advantages of small size, convenient operation, and precise forming.


Equipment Technical Parameter

Name

Parameters

Remarks

Crimping Stroke

About 30mm

Crimping Efficiency

60 seconds/piece

Reference to CR2032

Crimping Die

CR2032 is standard

Customized

Dismantling Die

CR2032 is standard

Customized

Power Supply

AC220V/50Hz,

110V/60Hz

This equipment can be used inside a glove box.

Power

200W

Equipment Dimensions

≈L334*W257*H479mm

Size after Packaging

≈L500*W340*H820mm

Net Weight

≈28kg

Gross Weight

≈33kg

Usage Site

Can be used inside the glove box, please verify if the glove box space matches the equipment's outer dimensions

Warranty Period

1-year warranty, lifetime maintenance
