Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Hot DIP Galvanized Pressure Welded 40 60 Pitch Steel Grating for Platform and Walkways
Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description

Steel bar grating, known for its high strength and robust structure, is manufactured from carbon steel, aluminum, or stainless steel. Depending on the production method, steel grating can be categorized into four types: welded bar grating, press-locked grating, swage-locked grating, and riveted grating. Based on surface design, it is available in both smooth and serrated options. With a wide range of styles and sizes, steel grating serves versatile applications in everyday life, including stair treads, walkways, platforms, flooring, trench covers, wheeled equipment, security screens, and heavy-duty constructions.


Product Recommendation

1. The grating with a pitch of 30mm between bearing bars is the most used type in the industrial field. Among normal types, it has the strongest resistance to surface lash.

2. The grating with a pitch of 40mm between bearing bars is the most economical and lightest type. It is the best choice for you on occasions when the span is small.

3. The grating with a pitch of 60mm between bearing bars and a pitch of 50mm between the cross bars is developed specially for mining industry, it solved the problem of mineral splash on the plate. So it is often appointed to use in processing works of mining industry.

4. The grating with the pitch of 30mm between bearing bars and the pitch of 76mm between cross bars is the most popular type used at home and abroad, it is proper for many applications such as walkways, platforms, etc.


General Parameter

Bearing Bar pitch(mm) 15,22,25,30,32.5,34,40,50,60,80,90 mm.
The pitch of 25,30,34 and 40 are recommended.
Bearing Bar Thickness(mm) 3-16mm
Bearing Bar Width(mm) 10-150mm
Cross bar pitch(mm) 24-200 mm.
The pitch of 50,76, 100 are recommended.
Bearing bar type Plain, Serrated, I-section.
Surface treatment Hot galvanized, Painted, Untreated.
Material Stainless Steel/ Low Carbon steel
