Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
Specifications
Brand Name :
Tian Rui
Model Number :
QB-0060/6006
Certification :
ROHS
Place of Origin :
China
MOQ :
10
Price :
Negotiable
Payment Terms :
D/P, T/T,Paypal, Visa, Mastercard
Supply Ability :
1000000PCS/Month
Delivery Time :
5-7 Days
Packaging Details :
1PCS/Bag
Product Name :
Boat Marine RV Battery Switch
Switch Posistions :
2
Switch Type :
Single Circuit ON-OFF
Rated Current :
300A
Intermittent Rating :
500A (5 min)
Starting Rating 30 sec :
900A
Rated Voltage :
48V DC
Stud Size :
3/8"
Battery Inputs :
1
Mounting Holes :
Accept #10 Screw
Stud Material :
Tinned Copper
Cable Size to Meet Ratings :
4/0 AWG (120mm²)
Description

2 Position Cut Off 32V 48V DC Marine Boat Yacht RV 6006 Battery Isolator Switch Disconnect Switch

This product is suitable for passenger cars, trucks, tractors, professional racing cars, and now it has been applied to many ordinary RVs abroad. At present, this kind of modification combination switch is used in many coastal cities in China, and the installation is simple.

Specification

Product Name Boat Marine RV Battery Switch
Switch Type
Single Circuit ON-OFF
Color
Red
Switch Positions
2
Maximum Voltage
32V DC
Continuous Rating
300A
Intermittent Rating
500A (5 min)

Starting Rating 30 sec
900A
Stud Size
3/8"
Battery Inputs
1
Mounting Holes
Accept #10 Screw
Stud Material
Tinned Copper
Terminal Stud Size
3/8" - 16 (M10)
Cable Clearance For 4/0 AWG Cables 1.12in (28.45 mm)
Cable Size to Meet Ratings 4/0 AWG (120mm²)
Stud Torque 120 in-lb (13.56 Nm)
Switching Rating 25A
Weight 0.65lb (0.29 kg)

Features

Switches a single battery to a single load group

•Ignition protected—safe for installation aboard gasoline powered boats

•Case design allows surface, front panel, or rear panel mounting

•Isolating cover with snap-on sections protects rear contacts

Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off

Function of 4 Position Cut Off 32V 48V DC Marine Boat Yacht RV Battery Isolator Switch Disconnect Switch

Prevent leakage, protect the power supply, disconnect the battery safely

Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off

Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off

Application of 4 Position Cut Off 32V 48V DC Marine Boat Yacht RV Battery Isolator Switch Disconnect Switch

The product has a wide range of uses and can be used as the on/off key for various electrical equipment added inside and outside the car (such as: strobe lights, chassis lights, fog lights, dome lights. Instantaneous power failure, etc.)

Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off

Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off

Marine Boat Yacht 32V 48V DC RV 6006 Battery Isolator Switch 2 Position Cut Off
