Specifications
Brand Name :
TIANRUI
Model Number :
QB-0058/6004
Certification :
ROHS
Place of Origin :
China
MOQ :
10
Price :
Negotiable
Payment Terms :
D/P, T/T,Paypal, Visa, Mastercard
Supply Ability :
1000000PCS/Month
Delivery Time :
5-7 Days
Packaging Details :
1PCS/Small Box
Product Name :
Boat Marine RV Battery Switch
Continuous Rating :
300A
Intermittent Rating :
500A
Starting Rating 30 sec :
900A
Maximum Voltage :
48VDC
Switch Type :
Single Circuit ON-OFF
Stud Size :
3/8"
Stud Material :
Tinned Copper
Stud Torque :
120 in-lb (13.56 Nm)
Switching Rating :
25A
Color :
Red
Weight :
0.65lb (0.29 kg)
Description

Boat Sea Sytems 6004 M Series ON Off Locking Main Power Switch Battery Switch


Specification

Product Name
Boat Marine RV Battery Switch
Color Red
Switch Type
Single Circuit ON-OFF
Continuous Rating 300A

Intermittent Rating
500A
Starting Rating 30 sec 900A
Maximum Voltage 48VDC
Stud Size 3/8"
Stud Material Tinned Copper
Stud Torque 120 in-lb (13.56 Nm)
Switching Rating 25A
Terminal Stud Size 3/8" - 16 (M10)
Weight 0.65lb (0.29 kg)



Features

•Tin-plated copper studs for maximum conductivity and corrosion resistance

•Studs accept 3/8" (M10) ring terminals

•7/8" (22 mm) stud length accepts multiple cable terminals

•One-piece terminal stud design never loosens over time

•One-piece stainless flange nuts ensure safe and secure connections

•Isolating cover protects rear contacts

•Breakout tabs allow wire access in any direction


Function

Prevent leakage, protect the power supply, disconnect the battery safely.


Application

This battery master switch is widely used for Car, Marine, Boat, RV, Camper, Travel Trailer, Truck, ATV, UTV, Battery banks and other 0-48V Devices.
