Aluminum Cabinet Large Led Screen Curtain , Led Panel Screen Evironment Protection
Aluminum Cabinet Large Led Screen Curtain , Led Panel Screen Evironment Protection
Aluminum Cabinet Large Led Screen Curtain , Led Panel Screen Evironment Protection
Aluminum Cabinet Large Led Screen Curtain , Led Panel Screen Evironment Protection
Specifications
Brand Name :
Vios
Model Number :
P16.66
Certification :
UL EMC CE ROHS Fcc ISO90001 ETL SGS SAA
Place of Origin :
China
MOQ :
1 Set
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
Supply Ability :
5000pcs/one month
Delivery Time :
7-15days
Packaging Details :
Carton box / Flight case / Wooden box
Average power :
<300W/sq.m
Working temperature :
20ºC~+50ºC±10%
Frame frequence :
50/60Hz
Uniformity :
97%
Size of cabinet :
500mmx 1000mm x 55mm
Weight of Cabinet :
<8.2KGS
Material of Cabinet :
Aluminum
Color temperature :
3200-9300k
Description

IP65 P16.66 LED curtain display high brightness 7000cd/m2 500mm x 1000mm cabinet

Product description:

  • Independent driving circuit with super thin power supply;
  • Aluminum cabinet with light weight and lasting,long life span;
  • High definition, Good uniformity；
  • high strength, anti-aging fabrics, IP66 protection grade, can withstand any bad environment test;
  • Can be fixed install or hung for rental, packed with flight case, good protection and easy to move;
  • High level: High level protection, front and rear can reach to IP65;
  • Transparent design, light transmittance up to 25%, good lighting and wind transparent, good heat dissipation,special design for stage background;
  • Independent driving circuit, equiped slim power supply, no fans no noise,good evironment protection;
  • SMD led encapsulation confirm wide view angle up 140 degree for horizontal and vertical;
  • Brightness can be adjusted between 2000 and 4000nits, suit to different request on brightness of inddor and outdoor;


Parameter:

P16.66 Indoor full Color LED Mesh Curtain Specification
Pixel pitch 16.66mm
Pixel Configuration 16.66mm
LED component DIP346
Resolution of cabinet 30x60
Material of Cabinet Aluminum
Weight of Cabinet <8.2KGS
Brightness >7000cd/sq.m
Density 3600dots/sq.m
Best viewing angle 110 /50
Best viewing distance 16-200M
Size of cabinet 500mmx 1000mm x 55mm
Color temperature 3200-9300k
Maximum power consumption <800W/sq.m
Average power consumption <300W/sq.m
Driving method static
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
IP grade IP65
Life Span 100,000 hours
Data transafer method RJ45
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1920Hz
Pratical standard CCC TUV-CE ETL etc.
Effectivce Communication Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Distance(without relay) Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World.
