Specifications
Controller Ic :
JD9851A
Supply Voltage :
3.1V
Display Type :
IPS TFT Panel
Packaging Details :
Tray + Inner Box + Carton
Display Size :
1.69 inch
Product Name :
1.69 TFT Display 240x280 Resolution Wearable LCD SPI TFT Module With Capacitive Touch Panel
MOQ :
1 piece
Dimensions :
35.04mm x 41.24mm x 3.46mm
Payment Terms :
T/T, L/C, Credit card, Cash
Operating Temperature :
-20°C to 70°C
Model Number :
KWH017ST01-C01
Place of Origin :
China
Color :
Color
Interface :
15Pin, 4W SPI
Resolution :
240 x 280
Brand Name :
Formike
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Viewing Angle :
All
Supply Ability :
5000000000 pieces/year
Description

1.69 TFT Display 240x280 Resolution Wearable LCD SPI TFT Module With Capacitive Touch Panel

Wearable Transparent SPI TFT LCD Screen Module 240x280 With Capacitive Touch Panel

Product Name1.69 TFT Display 240x280 Resolution Wearable LCD SPI TFT Module With Capacitive Touch Panel
LCD Size1.69 Inch TFT LCD Display Module or 1.7 Inch
Display ModeIPS
Resolution240x280
Outline Dimension (mm)35.04x41.24x3.46
Active Area (mm)27.97x32.63
Dot pitch (mm)0.11655x0.11655
Viewing DirectionAll
InterfaceSPI Interface, 15 Pin
Driver ICJD9851A
Brightness (Cd/m2)300
Contrast Ratio800:1
Backlight3 White LED

Backlight Supply
(Current/Voltage)

60mA 3.1V
Touch ScreenWith Capacitive Touch Panel

* KWH017ST01-C01 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, CTP.

* It is 240x280 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
