Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Specifications
Certification :
ISO9001, ISO14001, OHSAS18001, CCC
Place of Origin :
China
Brand Name :
Shacman X3000
Model Number :
CLW
MOQ :
1
Price :
15000-35000 per unit
Packaging Details :
Nude
Delivery Time :
65 working days after deposit
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
500PCS/Week
Model NO. :
Shacman X3000
Condition :
New
Maximum Lifting Height :
15-20m
Maximum Lifting Weight :
8-10t
Shaft Number :
3
Crane Jib :
Three-Arm
Type :
Folding
Product Name :
Ruck Monted Crane Telescopic Boom Lifting Mac
Driver Type :
4*2
Crane :
12ton
Lorry Capacity :
30ton
Cabin :
Left Hand Driving, Remote Front Door Lock, with a/
ABC :
Equipped
Engine :
6 Cylinders
Power :
180kw/245HP
Emission Standard :
Euro 3
Displacement :
6.7L
Fuel Type :
Diesel
Gearbox :
9 Forward & 1 Reverse Gear
Front and Rear Axle Load :
7t/10t
Wheel Base :
5700+1300(mm)
Overhang( Front/Rear) :
1460/2350(mm)
Transport Package :
Nude Packing or Roro Ship
Specification :
11900x2500x3850 (mm)
Trademark :
Shacman X3000
Origin :
China
HS Code :
871631100
Package Size :
1.00cm * 1.00cm * 1.00cm
Package Gross Weight :
1.000kg
Customization :
Available
After-sales Service :
12 Month
Warranty :
10 Year
Shipping Cost :
Contact the supplier about freight and estimated delivery time.
  :
Support payments in USD
Secure payments :
Every payment you make on Made-in-China.com is protected by the platform.
Refund policy :
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Manufacture :
Chengli Special Automobile Co.,Ltd
Description
Shacman X3000 GSQZ430 Truck Folding Crane Construction Boom Crane


Truck crane ,also called boom truck crane,mobile truck crane , truck mounted crane , hydraulic folding truck crane,telescopic straight boom crane,truck with crane , crane lorry,hydraulic arm crane for trucks,pickup truck mounted crane,light truck with crane,folding arm hydraulic lift platform,hydraulic crane telescopic boom,mobile crane price ,self loader truck with boom crane,new forland lorry truck mounted crane,telescopic boom truck mounted crane,flatbed knuckle boom truck crane,6 wheelers truck with crane boom truck cranes sale etc


A crane mounted on a truck carrier provides the mobility for this type of crane. This crane has
two parts: the carrier, often referred to as the Lower, and the lifting component which includes the
boom, referred to as the Upper. These are mated together through a turntable, allowing the upper
to swing from side to side. These modern hydraulic truck cranes are usually single-engine machines, with the same engine powering the undercarriage and the crane. The upper is
usually powered via hydraulics run through the turntable from the pump mounted on the lower. In
older model designs of hydraulic truck cranes, there were two engines. One in the lower pulled the
crane down the road and ran a hydraulic pump for the outriggers and jacks. The one in the upper ran
the upper through a hydraulic pump of its own. Many older operators favor the two-engine system
due to leaking seals in the turntable of aging newer design cranes.


Technical date :
Product name Shacman X3000 6x4 truck with 12 ton stiff boom crane Max Speed 89km/h Crane 12/14/16 ton stiff boom crane
Chassis Brand Shacman X3000 Axles 3 Arms sections 4-5
Rated loading weight 15000KG Engine Brand Weichai Max lifting capacity 16 ton
Curb weight 19000KG Horse Power 340hp Max lifting height 21.5m
Dimensions 12000x2450x3560mm Emissions 2088ml Max working radius 19.5m
Cargo body dimension 800x2300x550mm Cab one and half row Operation pressure 30mpa
Wheelbase 5770+1350mm Tire 10+1 Deadweight of crane 4600kg

Drive type		 6x4 LHD/RHD Gross weight 25000kg Rotation angle 360 full rotation

Chassic :

CNHTC , Beiben trucks , Shacman trucks , FAW trucks , I SUZU ,Hongyan trucks,FOTON trucks , Dongfeng trucks , JAC trucks



Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Application:

For general cargo lifting and other special things like timber and brick by changing other equipment.

Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane

Details :
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14
millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).

Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
Overseas Market
Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in
Asia, Africa, South America, middle east and so on, such as Russia, Mongolia, Philippines, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, Uzbekistan,
Kyrghzstan, Tanzania, Zambia, Nigeria, Australia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina and also truck body for client drawing
Shacman X3000 Gsqz430 Folding Crane Truck 12ton Mobile Construction Boom Crane
