Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Stainless Steel Seamless Boiler Tube Heat Transfer Pipe ASME SA213 SUS304
Specifications
Brand Name :
YUHONG
Model Number :
TP304, 1.4301, SUS304
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China, Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 60 Days
Packaging Details :
Ply-Wooden Case & Woven Bag
Material :
TP304, 1.4301, SUS304
Standard :
ASME SA213 , ASTM A213
Type :
Coil, Straight, U bend
NDT :
UT, ET, HT, PMI
Size :
OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc
Application :
Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle
Description
Stainless Steel Seamless Tube ASME SA213 TP304 1.4301 SUS304 For Petrochemical
Product Specifications
Attribute Value
Material TP304, 1.4301, SUS304
Standard ASME SA213, ASTM A213
Type Coil, Straight, U bend
NDT UT, ET, HT, PMI
Size OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle
Product Description

Stainless Steel Seamless Tube, ASTM SA213 TP304 (1.4301, SUS304) For Petrochemical Application

The designation ASME SA213 indicates that the tube meets the specifications set by the American Society of Mechanical Engineers (ASME) for seamless ferritic and austenitic alloy-steel boiler, superheater, and heat exchanger tubes. ASME SA213 outlines the necessary testing procedures, including hydrostatic tests, non-destructive testing, and dimensional inspections, to verify the quality and safety of the tubes.

TP304 has good resistance to a wide range of corrosive environments, although it may not be suitable for chloride-containing environments, which can lead to pitting corrosion. TP304 is a type of austenitic stainless steel, primarily composed of iron, chromium (18-20%), and nickel (8-10.5%). This composition gives it excellent corrosion resistance and good weldability.

Chemical Composition
Grade Cr Ni C
SA213 TP304 18.0-20.0% 8-10.5% ≤ 0.08%
Mechanical Properties
Grade Tensile Strength Yield Strength Elongation Hardness
SA213 TP304 ≥ 205 MPa (30 ksi) ≥ 515 MPa (75 ksi) ≥ 35% in 50 mm Typically ≤ 90 HRB
Applications
  • Chemical Processing: Heat exchangers for mild chemicals and process piping requiring moderate corrosion resistance.
  • Food and Beverage Industry: Processing equipment resistant to food acids, ideal for dairy and beverage systems.
  • Water Treatment: Condenser tubes for fresh water systems ensuring longevity and reliability.
  • HVAC Systems: Coils and heat exchangers for efficient heat transfer in moderate temperature environments.
  • Pharmaceutical Industry: Process equipment ensuring cleanliness and corrosion resistance in sensitive processes.
