Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Nickel Alloy Marine Heat Exchanger Tube SA179 Carbon Steel ASME SB677 TP904L
Specifications
Brand Name :
YUHONG
Model Number :
Seamless Tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 60 Days
Packaging Details :
Ply-Wooden Case & Woven Bag
Material :
TP904L
Standard :
ASTM B677 , ASME SB677
Ends :
PE , BE
Testing :
UT, ET, HT, PMI
Size :
OD : 6mm~ 50.8mm , WT: 0.5mm~ 15mm, L: Max:34m/pc
Application :
Heat Exchanger, Cooling , Heating, Condenser, Tube Bundle
Description
Nickel Alloy Steel Heat Exchanger Tube ASME SB677 TP904L In Petrochemical Industry
Product Specifications
Attribute Value
Material TP904L
Standard ASTM B677, ASME SB677
Ends PE, BE
Testing UT, ET, HT, PMI
Size OD: 6mm~50.8mm, WT: 0.5mm~15mm, L: Max:34m/pc
Application Heat Exchanger, Cooling, Heating, Condenser, Tube Bundle
Product Description

The Nickel Alloy Steel Heat Exchanger Tube ASME SB677 TP904L is a high-performance solution designed for extreme corrosion resistance in harsh industrial environments. Manufactured from TP904L stainless steel, this super austenitic alloy features elevated levels of chromium, nickel, and molybdenum for superior durability.

TP904L Stainless Steel offers enhanced corrosion resistance with its low carbon content and high alloy composition. The tubes comply with ASME SB677 specifications, ensuring adherence to rigorous industry standards for quality and performance in demanding applications.

Chemical Composition
Grade Cr Ni Mo Cu C
TP904L 19.0-23.0% 23.0-28.0% 4.0-5.0% 1.0-2.0% 0.02% max
Mechanical Properties
Grade Tensile Strength Yield Strength Elongation Hardness
TP904L ≥ 220 MPa (32 ksi) ≥ 490 MPa (71 ksi) ≥ 35% in 50 mm Typically ≤ 90 HRB
Industrial Applications
  • Petrochemical Industry: Heat exchangers in refineries and chemical processing equipment handling aggressive chemicals
  • Power Generation: Boiler feedwater heaters and heat recovery steam generators in power plants
  • Marine Applications: Cooling systems for ships and offshore platforms requiring seawater corrosion resistance
  • Pharmaceuticals: High-purity process equipment meeting strict health regulations
  • Food and Beverage: Pasteurization equipment and heat recovery systems
  • Aerospace and Defense: Heat exchangers in aircraft engines
  • Nuclear Power Plants: Secondary cooling loop systems
  • Cryogenic Applications: LNG heat exchangers
  • Environmental Technology: Waste heat recovery systems
