Specifications
Brand Name :
YUHONG
Model Number :
Seamless Tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 60 Days
Packaging Details :
Ply-Wooden Case + Iron Frame
Material :
C70600
Standard :
ASTM B466 , ASME SB466
Ends :
PE , BE
Application :
Heat Exchangers, Condensers, Coolers, Etc.
Description
ASTM B466 C70600 Copper Alloy Steel Heat Exchanger Tube For Coolers
Product Specifications
Attribute Value
Material C70600
Standard ASTM B466, ASME SB466
Ends PE, BE
Application Heat Exchangers, Condensers, Coolers, Etc.
Product Description

ASTM B111 C70600 Copper Alloy Steel Heat Exchanger Tube For Coolers

ASTM B466 specifies seamless copper-nickel alloy tubes for heat exchangers, condensers, and similar applications. The C70600 alloy meets rigorous requirements for mechanical properties, corrosion resistance, and heat transfer performance.

C70600 copper-nickel alloy tubes offer exceptional corrosion and biofouling resistance, ensuring long service life with minimal maintenance. Their superior thermal conductivity and mechanical strength enable efficient heat exchange in demanding environments, including high-pressure systems and extreme conditions like offshore platforms and marine applications.

Chemical Composition
Grade Cu Ni Fe
ASTM B466 C70600 88.7-90.3% 9-11% 1-1.8% (for strength and corrosion resistance)
Mechanical Properties
Grade Yield Strength Tensile Strength Elongation
ASTM B466 C70600 Approximately 105 MPa (15 ksi) Approximately 275 MPa (40 ksi) ≥ 30%
Applications
  • Cooling Systems in Naval Vessels: Resists corrosion from saltwater in continuous marine operations.
  • Heat Exchanger Tubes for Nuclear Power: Performs reliably in high-pressure nuclear cooling systems.
  • Offshore Platform Cooling: Ideal for seawater cooling systems in oil rigs and gas platforms.
  • Chemical Plant Heat Exchangers: Withstands aggressive chemicals and high temperatures in industrial processes.
