60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance
60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance
60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance
60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance
60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance
60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance
Specifications
Brand Name :
HSF
Model Number :
CPP60RB-25
Place of Origin :
China
MOQ :
2000kg
Payment Terms :
T/T
Supply Ability :
5 tons per day
Delivery Time :
15 working days
Packaging Details :
Export Standard
Material :
Polypropylene
Color :
Red / Black
Surface Finish :
Double-sided glossy, single-sided matte & glossy, or double-sided matte; 25μm emboss depth.
Thickness :
40μm-330μm
Web Width :
Up to 2100mm
Description
60μm CPP Red-Black Dual-Color Embossed Film
This premium cast polypropylene film features a distinctive red-black dual-color design with precise 25μm emboss depth, offering exceptional visual appeal and functional performance for packaging applications.
Production Process
Manufactured using advanced cast extrusion and precision embossing technology. High-purity CPP resin is melted in temperature-controlled extruders (160-180℃), then co-extruded with red and black masterbatches to create a dual-color base film with consistent 60μm thickness. The material undergoes precision embossing to achieve 25μm uniform emboss depth, followed by trimming, tension control, and winding into defect-free rolls.
Key Features
  • 60μm base thickness with 25μm uniform emboss depth
  • Vivid red-black dual-color co-extrusion with excellent color fastness
  • Smooth, even embossed surface with superior scratch resistance
  • Balanced tensile strength and tear resistance with good flexibility
  • Compatible with lamination and heat-sealing processes
  • Optional food-grade certification available
Product Advantages
The 60μm base thickness provides optimal balance between flexibility and durability, while the 25μm emboss depth enhances texture and anti-slip performance. The distinctive red-black dual-color design offers unique aesthetic appeal for packaging applications. Excellent batch-to-batch consistency in color, thickness, and emboss pattern minimizes production waste. Non-toxic, odorless, and easy to process, this film combines practicality with visual appeal for cost-effective mass production.
60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance 60μm Red-Black Dual-Color Cast Polypropylene Film with 25μm Emboss Depth for High Tensile Strength and Tear Resistance
Application Environment
Widely used in food packaging, gift packaging, cosmetic packaging, and industrial packaging applications. Performs reliably in dry, normal-temperature environments (0℃ to 60℃) and moderate storage conditions. Suitable for high-speed slitting, lamination, heat-sealing, and printing processes. Ideal for customers seeking both aesthetic appeal and practical performance in packaging materials.
Product Specifications
Test Item Unit Industry Standard Requirement Product Specified Standard Actual Test Result Qualification Judgment
Base Film Thickness (excl. emboss) μm 60±5 60±3 59.6 Qualified
Emboss Depth μm 25±3 (customizable) 25±2 24.9 Qualified
Tensile Strength (MD/TD) MPa ≥16/≥14 ≥18/≥16 19.3/17.2 Qualified
Elongation at Break (MD/TD) % ≥260/≥210 ≥280/≥230 292/245 Qualified
Heat Seal Strength (120℃, 0.3MPa, 1s) N/15mm ≥8 ≥10 11.5 Qualified
Surface Tension (corona treated side) mN/m ≥38 ≥40 40.8 Qualified
Tear Resistance (MD/TD) N ≥13/≥10 ≥14/≥11 15.2/12.4 Qualified
Moisture Barrier Property (23℃, 85%RH) g/(m²·24h) ≤6.0 ≤5.5 5.2 Qualified
Oil Resistance (soaked in n-hexane for 24h) - No obvious swelling, discoloration No swelling, discoloration, adhesion No swelling, discoloration, adhesion Qualified
Hardness (Shore D) HD 51±5 51±3 50.9 Qualified
Emboss Adhesion - No texture peeling by tape test No texture peeling, color fading by 3M tape test No texture peeling, color fading by 3M tape test Qualified
Weather Resistance (UV aging for 72h) - No obvious fading, cracking Fading grade ≤2, no cracking, deformation Fading grade 1, no cracking, deformation Qualified
Environmental Performance (food contact grade) - Compliant with GB 4806.7-2016 Compliant with GB 4806.7-2016, no peculiar smell, no harmful precipitation Compliant with GB 4806.7-2016, no peculiar smell, no harmful precipitation Qualified
