90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging
90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging
90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging
90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging
90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging
90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging
Specifications
Brand Name :
HSF
Model Number :
CPP90YB-25
Place of Origin :
China
MOQ :
2000kg
Payment Terms :
T/T
Supply Ability :
5 tons per day
Delivery Time :
15 working days
Packaging Details :
Export Standard
Material :
Polypropylene
Color :
Yellow / Black
Surface Finish :
Double-sided glossy, single-sided matte & glossy, or double-sided matte; 25μm emboss depth.
Thickness :
40μm-330μm
Web Width :
Up to 2100mm
Description
90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film
Premium cast polypropylene film engineered for high-end stationery and industrial packaging applications, featuring exceptional stiffness, vivid dual-color appearance, and superior mechanical properties.
Production Process
Manufactured using precision co-extrusion casting and high-torque embossing technology. High-purity CPP resin is processed at 160-180°C, co-extruded with high-opacity yellow and black masterbatches to form a 90μm dual-color base film (22μm yellow top layer/68μm black bottom layer). After precision cooling and shaping, the film undergoes embossing at 100-110°C under 0.2-0.3MPa pressure for uniform 25μm fine cloth grain finish, followed by corona treatment, micro-trimming, and tight winding to produce defect-free rolls with ultra-low batch deviation (≤3%).
Core Features
  • 90μm ultra-stiff heavy-gauge base film with 25μm uniform emboss depth
  • High-visibility vivid yellow-black dual-color with industrial-grade color fastness
  • Superior mechanical performance: tensile strength ≥24/22MPa (MD/TD)
  • Excellent tear resistance ≥17/14N (MD/TD) and Shore D hardness 57±3HD
  • Corona-treated surface (≥40mN/m) for high-definition printing compatibility
  • Robust heat seal strength (≥13N/15mm) with upgraded oil/moisture barrier
  • Food-contact grade compliant (GB 4806.7-2016), odor-free and safe
Product Advantages
The 90μm ultra-stiff base film provides unmatched structural rigidity and robust toughness, resisting deformation for long-term heavy-duty use. The 25μm delicate emboss enhances anti-slip tactile grip and visual layering, while the high-visibility yellow-black color scheme offers exceptional safety warning and identification performance. Co-extrusion process ensures permanent color fastness without fading or bleeding, with excellent print and heat-seal compatibility for seamless post-processing.
90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging 90μm Base Film 25μm Emboss Depth Yellow-Black Dual-Color CPP Film for High-End Stationery and Packaging
Application Environment
Ideal for luxury stationery including high-end hardcover folder covers, premium thick notebook shells, and luxury album binders. Perfect for heavy-duty industrial safety warning and marking tapes due to excellent tear resistance and anti-slip performance. Also suitable for premium medium food packaging and heavy industrial protective packaging. Performs stably in 0°C-65°C environments and adapts perfectly to high-speed slitting, high-definition digital printing, and automated heat-sealing industrial processes.
Technical Specifications
Test Item Unit Product Specified Standard Actual Test Result Qualification
Base Film Thickness (excl. emboss) μm 90±3 89.7 Qualified
Emboss Depth μm 25±2 24.8 Qualified
Tensile Strength (MD/TD) MPa ≥24/≥22 25.1/23.4 Qualified
Elongation at Break (MD/TD) % ≥340/≥290 352/305 Qualified
Heat Seal Strength (120°C, 0.3MPa, 1s) N/15mm ≥13 14.3 Qualified
Surface Tension (corona treated side) mN/m ≥40 41.7 Qualified
Tear Resistance (MD/TD) N ≥17/≥14 18.2/15.3 Qualified
Moisture Barrier Property (23°C, 85%RH) g/(m²·24h) ≤4.0 3.8 Qualified
Oil Resistance (n-hexane, 24h) - No swelling, discoloration, adhesion No swelling, discoloration, adhesion Qualified
Hardness (Shore D) HD 57±3 56.8 Qualified
Emboss Adhesion - No texture peeling, color fading by 3M tape test No texture peeling, color fading by 3M tape test Qualified
Weather Resistance (UV aging for 72h) - Fading grade ≤2, no cracking, deformation Fading grade 1, no cracking, deformation Qualified
Environmental Performance (food contact) - Compliant with GB 4806.7-2016, no peculiar smell, no harmful precipitation Compliant with GB 4806.7-2016, no peculiar smell, no harmful precipitation Qualified
