2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-5588
Certification :
CE, SGS, UL, ROHS
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25000PCS Monthly
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Connector Type :
FDDI
Polish Type :
UPC
Fiber Mode :
Multimode
Color :
Beige
Fiber Count :
2
Cable OD :
3.0mm
Description

2.0mm Fiber Optic MTRJ Singlemode Duplex Field Assembly Connector

Description


Hangalaxy’s distribution box terminates outside optical cables with up to 12 fibers; it allocates 12 adapters for connecting with max 12 drop cable pigtails, it is also suitable for using with mini splitters. The box works under both indoor and outdoor environments. It is a perfect cost-effective solution-provider in the FTTH networks.


Keyed Characteristics


√ ABS material used ensures the body strong and light;
√ Protection Level: IP55;
√ Water-proof design for outdoor uses, lock provided for extra security;
√ Easy installations: Ready for wall mount – installation kit provided;
√ Adjustable adapter slotused – to suit different size pigtails;
√ Space saving! Double-layer design for easier installation and maintenance;
√ Lower layer for splicing, also suitable for mini splitters;
√ Upper layer for adapters, connectors and fiber distribution;
√ Cable fixing units provided for fixing the outdoor optical cable;
√ Both cable glands and tie-wraps accessible;
√ Pre-connectorized cables supported (pre-connected with fast-connectors);
√ Bend radius protected and cable routing paths provided.

Technical Parameter

Category Specification
Applicable for Ф2.0x3.0mm Indoor Flat Cable
Fiber mode 9/125μm Single-mode
Polish Type APC / UPC
Dimension 55mm
Housing Green / Blue PC Plastic
Ferrule Material Ceramic (Zirconia)
Operation time S About 50(no fiber cut)
Insertion Loss dB ≤ 0.50
Insertion Loss Typical value dB ≤ 0.30
Return Loss dB ≥ 45.0
Fastening strength of naked fiber N ≥ 5
Tensile strength N ≥ 50
Reusable Time ≥ 10 times
Operating Temperature ℃ -40～+75
On-line tensile strength (10N) dB ΔIL≤ 0.3
Mechanical durability (500 times) dB ΔIL≤ 0.3

Drop-off test

(drop-off height4m,once per direction,totally 3 times)

 dB ΔIL≤ 0.3
Conformance TIA/EIA 604-3

2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode

Features & Benefits

1. Versatile connector system with a RJ-45 form factor
2. Duplex ferrule
3. Increases port density required on computer and networking related hardware, panels, wall plates, and in closets by 50%
4. Meets TIA-568A standards
5. Low insertion loss:
<.22 dB TYP MM
<.19 dB TYP SM

Applications


(1) Premise infrastructure;
(2) Backbone;
(3) Horizontal;
(4) Local Area Networks (LAN's);
(5) Device terminations;
(6) Telecommunication networks.

2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode

Team Work Activities

2.0mm Duplex Fiber Optic Field Assembly Connectors FDDI MTRJ Singlemode
