QSFP28 100G ER4 40km Fiber Optical Transceivers Module 100GBASE-ER4
QSFP28 100G ER4 40km Fiber Optical Transceivers Module 100GBASE-ER4
Specifications
Brand Name :
Optowix
Model Number :
MLK-1Q-LR4ER
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Supply Ability :
10Kpcs
Delivery Time :
5-8 working days
Packaging Details :
ESD plastic case
Product Name :
QSFP28 100G ER4
SpeedRate :
100G
TX :
4X25G EML Laser
RX :
4X25G SOA receiver
Distrance :
40km
Warranty :
12 Months
Application :
Datacenter
Interface :
LC duplex
Description
100G ER4 40km QSFP28 Module Optical Transceiver Module,100GBASE-ER4
Features
  • Hot Pluggable QSFP28 form factor
  • Compliant with 100GBASE-ER4.
  • Support line rates to 103.125 Gbps
  • Integrated LAN WDM TOSA / APD ROSA, support 40km with FEC
  • Digital Diagnostics Monitoring Interface
  • Duplex LC optical receptacle
  • No external reference clocks
  • Electrically hot-pluggable
  • Compliant with QSFP28 MSA and 4WDM20_40 MSA with LC connector
  • Case operating temperature range:0°C to 70°C
  • Power dissipation < 5W

Applications
  • 100G Ethernet
  • Other optical links
Standards
  • SFF8679,SFF-8636
  • SFF-8665, SFF8661
  • IEEE 802.3ba,IEEE 802.3bm
Ordering Information
Part. No Specifications
Pack Rate Tx P Rx S Top Reach Other
(Gbps) (nm) (dBm) (dBm) (℃) (km)
MLK-1Q-LR4EL QSFP28 4x25.78 1295.56 -2.9~2.9 SOA <-19 0~70 40 RoHS
1300.05
1304.58
1309.14
