QH-GC3-S 3 Chucks Tube Cutting Machine Standard Model Weldseam Identification Horizontally-mounted Lathe
QH-GC3-S 3 Chucks Tube Cutting Machine Standard Model Weldseam Identification Horizontally-mounted Lathe
Specifications
Brand Name :
QIHAI
Model Number :
QH-GC3-S
Certification :
ISO, CE
Place of Origin :
Foshan, Guangdong, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100 set/month
Delivery Time :
40 days
Packaging Details :
wood
Laser Source :
IPG/Raycus/Maxphotonics
Control System :
Cypcut/Beckhoff
Positioning Accuracy :
±0.03mm
Laser Type :
Fiber Laser
Laser Power :
1000W/2000W/3000W/4000W
Power Supply :
AC380V/50Hz/60Hz
Repositioning Accuracy :
±0.02mm
Cutting Thickness :
0.5mm-25mm
Tube Length :
6000mm/8000mm/12000mm
Cooling Mode :
Water Cooling
Tube Diameter :
20mm-200mm
Cutting Speed :
0-15m/min
Warranty :
1 years
Automatic Loading :
Fully-automatic Loading
Description
QH-GC3-S 3 Chucks Tube Cutting Machine Standard Model Weldseam Identification Horizontally-mounted Lathe QH-GC3-S 3 Chucks Tube Cutting Machine Standard Model Weldseam Identification Horizontally-mounted Lathe
QH-GC3-S 3 Chucks Tube Cutting Machine Standard Model Weldseam Identification Horizontally-mounted Lathe

Description​

1. Description

The QH-GC3-S is a high-performance standard-model tube laser cutting solution engineered for heavy-duty industrial tube processing, integrating three core technologies: 3-chuck tube clamping system, automatic weldseam identification, and horizontally-mounted lathe structure.

Its horizontally-mounted lathe design provides stable, linear support for long tubes (5500-6500mm length capacity), eliminating sagging during processing—critical for maintaining precision across oversized workpieces. Paired with the 3-chuck clamping system, it distributes clamping force evenly across round tubes (Φ15-500mm) and square tubes (15×15-500×500mm), preventing deformation even when cutting thick-walled tubes (handled via 6000W-20KW laser power). The built-in weldseam identification technology automatically detects tube weld seams via high-resolution imaging, ensuring cuts avoid seam areas (a common cause of defective parts) while aligning with ±0.03mm X/Y-axis positioning and repositioning accuracy.
​
Quick Detail​

Triple-Core Tech: 3-chuck clamping (even force, no deformation) + weldseam identification (auto-seam avoidance) + horizontally-mounted lathe (stable 5500-6500mm tube support).

Key Specs: Cuts Φ15-500mm round/15×15-500×500mm square tubes; 6000W-20KW power (thick-walled compatibility); ±0.03mm dual-axis accuracy.

Efficiency & Reliability: 6T heavy-duty build (vibration resistance); standard model (no custom setup); fits 380V/50Hz industrial power (implied for compatibility).

Fit: Heavy machinery/pipeline industries; batch thick-walled tube processing.


Product Specifications
Model QH-GC3-S
Cutting Diameter Round Tube: Φ15-500mm
Square Tube: 15*15mm to 500*500mm
Tube Length Capacity 5500-6500mm
Machine Weight 6T
Dimensions (L*W*H) 16680*5480*2250mm
Laser Power Range 1500W-20KW
Positioning Accuracy ±0.03mm (X/Y-axis)
Repositioning Accuracy ±0.03mm (X/Y-axis)
Compatible Tube Types Round Tube / Square Tube
Automatic Loading Fully-automatic Loading


Advantage​

3-Chuck + Horizontally-mounted Lathe = Unmatched Stability for Long/Thick Tubes: The horizontally-mounted lathe’s linear support paired with 3-chuck clamping fixes 5500-6500mm long tubes firmly, avoiding sagging that causes cut deviation. For 20-25mm thick-walled carbon steel tubes (processed via 15-20KW power), this combination maintains ±0.03mm precision—reducing scrap rates by 35% vs. 2-chuck or vertical lathe models, as deformation and vibration are minimized.

Automatic Weldseam Identification Cuts Rework & Improves Quality: The integrated weldseam detection system scans tubes pre-cut to locate weld seams, then adjusts cutting paths to avoid these weak points. This eliminates manual seam checking (saving 2-3 minutes per tube) and prevents defective cuts (e.g., cracks at seams) that require rework—boosting finished part yield by 40% for seam-containing tubes (common in industrial pipelines and structural trusses).

Triple Tech Integration Boosts Batch Efficiency: The 3-chuck system enables fast tube loading/unloading (10 seconds faster per tube than manual clamping), the horizontally-mounted lathe accommodates full-length 6500mm tubes without segmentation, and weldseam identification skips manual setup. Combined with 6000W-20KW power (single-pass cutting for 15mm thick tubes), these features cut batch processing time by 30% vs. traditional machines. As a standard model, it also avoids custom installation costs, making it a cost-effective solution for businesses scaling tube production.
