High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
Specifications
Brand Name :
Qingdao Zhenxiong
Model Number :
SWP - 360
Place of Origin :
Qingdao,China
MOQ :
1 set
Price :
900 - 9000 USD per set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets per month
Delivery Time :
15 - 25 working days
Packaging Details :
After being wrapped with stretch film , it is shipped unpacked in the container .
Knife roller speed :
120 - 520 rpm
Rotating blade diameter :
360mm
Bearing :
Grade 1
Configuration :
Different models and configurations can be customized
Description

High Capacity Plastic Auxiliary Equipment Plastic Crusher Fast Shredding

This series of crushers has strong crushing capacity, with motor power ranging from 5.5 to 75 kilowatts, blade roller speed generally between 120 and 520 rpm, and large crushing space with high production capacity.

Core advantages:
●The crusher adopts alloy steel blades, which are sturdy, wear-resistant, reduce replacement frequency, and lower production costs.
●The crusher body is made of welded steel plates, with a compact structure, strong seismic resistance, and long service life.
●Small footprint, easy to install and arrange in limited space.


●The design of the large feed inlet for this series of crushers makes feeding convenient, and larger materials can be directly fed into the crusher.
●Structurally, there are two types of feed: tangential feed and top feed. The knife rollers are different from solid knife rollers and hollow knife rollers.
●With sieve: The particle size of the discharged material is uniform and can be customized according to customer requirements.
●The crusher is designed to be easy to disassemble, convenient for maintenance, and easy to clean.
●High cost-effectiveness: The model has a relatively simple design structure, strong practicality, and relatively low price.

Application scope:
It is generally widely used in industries such as plastics, chemicals, and resource recycling, for the recycling and reuse of broken waste plastics and factory scraps.

SWP360

Motor power

11KW

Number of rotating blades

3pcs

Bearing

Grade 1

Number of fixed blades

2pcs

Rotating blade diameter

360mm

Screen plate aperture

10mm

Weight

800-900kg

High Capacity Plastic Crusher Fast Shredding Plastic Auxiliary Equipment
