Customized Sizes Environmentally Friendly Metal Carved Board For Prefabricated Panel Houses
Customized Sizes Environmentally Friendly Metal Carved Board For Prefabricated Panel Houses
Specifications
Brand Name :
HY
Model Number :
09
Place of Origin :
Tianjin,China
MOQ :
1 piece
Payment Terms :
Prepayment starting from 30%
Supply Ability :
1000m per day (in stock)
Delivery Time :
3 days
Packaging Details :
Packaging of individual items
Style :
Modern
Waterproof grade :
IP65. The top and joints are sealed with ethylene propylene diene monomer (EPDM) rubber
Customization :
Customized as needed
Application :
K value ≤1.5W/(㎡ · K), and it can maintain an indoor temperature difference of ≤8℃ in an environment ranging from -10℃ to 40℃
Service life :
15 years
Fire resistance grade :
The wall panels and floors meet the B1 grade flame-retardant standard
Folded dimensions :
length 6000mm× width 2400mm× height 1600mm
Description
Environmentally friendly prefabricated movable panel houses - available in multiple scenarios and supporting customized sizes
Core Features: Prefabricated Standardization and Rapid Deployment Capability​
Prefabricated movable board houses adopt a fully industrialized production mode. All components are prefabricated and processed in the factory, and only modular splicing is needed on site, which greatly shortens the construction period. It takes a steel structure as the framework and is matched with color steel sandwich panels as walls and roofs, having both structural stability and thermal insulation performance. Compared with traditional temporary buildings, its advantage lies in flexible disassembly and reusability. The turnover times of a single set of equipment can reach more than 5 times, which can effectively reduce the long-term use cost, and it is especially suitable for short-term projects or emergency scenarios.​
Technical Parameter Configuration Table​
​
Parameter Category​
Basic Model Specification​
Main Structure​
Light steel structure + 50mm color steel sandwich panel​
Single Unit Size​
6m×3m×2.8m (Area 18㎡)​
Wind Resistance Level​
6-7 grades​
Fire Resistance Level​
Class B2 (flame-retardant)​
Single Unit Weight​
About 1.2 tons​
Installation Personnel × Time​
3 people × 1 day / single unit​
Maximum Combined Units​
10 units (connected without gaps)​
Adaptable Temperature Range​
-10℃~40℃​



​
Typical Application Scenarios​
  • Engineering Construction Field: As dormitories for construction workers and temporary project offices, it meets the basic living and office needs of field stations. After the project is completed, it can be moved to a new construction site as a whole for reuse.​
  • Emergency Support Scenarios: Temporary resettlement sites after natural disasters such as earthquakes and floods, or isolation observation areas in public health incidents, which can complete batch deployment within 48 hours.​
  • Commercial Temporary Spaces: Temporary exhibition halls during exhibitions, ticket offices and rest areas for festival activities, which can flexibly adjust the combination mode according to the scale of the activities.​
  • Agricultural and Mining Assistance: Temporary rest rooms in remote mining areas and care houses in farmland, adapting to the field environment without fixed building conditions.​
One-Sentence Q&A​
  1. How many people can a single unit board house accommodate for office use?​
The basic model can accommodate 6-8 people (4 desks + meeting area), and the upgraded model can be expanded to 10 people.​
  1. Is professional foundation treatment required?​
No concrete foundation is needed. It can be placed on hardened ground or gravel cushion, and the flatness error must be ≤ 5cm.​
  1. How about the warmth retention in winter?​
The upgraded sandwich panel contains a high-density insulation layer, and the indoor temperature can be maintained above 10℃ in a -10℃ environment (heating equipment is required).​
  1. Will there be leakage in heavy rain?​
The joints are treated with sealing strips + profiling, which can resist moderate to heavy rain, with an annual leakage rate of less than 5%.​
  1. Can it be quickly put into use after long-term idle?​
After being idle for 1 year, only cleaning and checking the circuit are needed, and the use function can be restored within 2 hours.
