Specifications
Brand Name :
HY
Model Number :
09
Place of Origin :
Tianjin,China
MOQ :
1 piece
Payment Terms :
Prepayment starting from 30%
Supply Ability :
1000m per day (in stock)
Delivery Time :
3 days
Packaging Details :
Packaging of individual items
Style :
Modern
Overall frame material :
Hot-dip galvanized Q235 steel, thickness 3mm
Functional Zoning :
1 bedroom + 1 living room + 1 micro shop
Service life :
The main structure ≥15 years, and the wear parts (such as sealing strips) ≥5 years
Wind Resistance Level :
Level 10
Single Container Weight :
Approximately 3.5 tons
Fire resistance grade :
The wall panels and floors meet the B1 grade flame-retardant standard
Description

Modular integrated box-type units that can be fully customized for hotel and retail Spaces


Core Advantages: Modular Design Adapting to Commercial Scenario Needs

Modular integrated container units are based on standardized containers, enabling the rapid construction of hotel rooms and retail stores through factory prefabrication and on-site assembly. They adopt high-strength steel structure frames and fireproof insulation wall panels, combining safety and comfort. Each container module can be used independently or combined with multiple units, flexibly adapting to commercial spaces of different scales. Compared with traditional buildings, the construction period of these units is shortened by more than 60%, with a single container taking only 24 hours to install. They also support personalized interior customization to meet the themed design needs of hotels and brand display requirements of retail spaces, especially suitable for scenarios sensitive to construction cycles such as cultural tourism scenic spots and commercial blocks.


Technical Parameter Configuration Table

Parameter Category Hotel-Specific Model Specifications Retail-Specific Model Specifications
External Dimensions of Single Container 6m×3m×3.2m (net height 2.8m) 6m×3.5m×3.2m (net height 2.8m)
Main Material Hot-dip galvanized steel frame + 100mm rock wool insulation board Hot-dip galvanized steel frame + 80mm composite insulation board
Internal Usable Area Approximately 16㎡ (including independent bathroom) Approximately 20㎡ (open layout)
Wind Resistance Level Level 11 Level 11
Fire Resistance Level Class A (walls + floors) Class A (walls + floors)
Supporting Systems Independent air conditioning + fresh air system + intelligent guest control Commercial-grade power supply + window display lighting + intelligent monitoring
Weight of Single Container Approximately 4.2 tons Approximately 3.8 tons
Combination Method Can be stacked up to 3 floors + unlimited horizontal splicing Can be horizontally spliced + partial high-rise design


Typical Application Scenarios

  • Modular Hotels: In scenic spots, "container clusters" are used to create characteristic homestays. A single container serves as an independent guest room, equipped with panoramic floor-to-ceiling windows and smart home systems. Multiple containers are combined to form a courtyard-style layout, balancing privacy and landscape.
  • Pop-up Retail Spaces: Brand pop-up stores are quickly built in commercial plazas. The exterior of the container unit can be customized with spray painting or LED screens, and the interior can flexibly display products. After the event, it can be relocated to other venues for reuse.
  • Commercial Street Renovation: In old street renewal projects, integrated container units are used to supplement retail formats. Without large-scale demolition, more than 10 stores can be built within 30 days, quickly activating the vitality of the street.


One-Sentence Q&A

  1. Can the hotel model meet the sound insulation requirements of star-rated guest rooms?
    The walls are filled with high-density sound insulation cotton, and the indoor noise is ≤35 decibels, meeting the four-star hotel standard.
  2. Can the power supply system of the retail model support large-scale display cabinets and equipment?
    It is equipped with a standard 380V industrial power interface with a total load of 15kW, which can meet the simultaneous operation of refrigerators, display cabinets and other equipment.
  3. After multi-container combination, are there any water leakage or structural safety hazards?
    The splicing joints adopt waterproof sealing technology + steel structure reinforcement, and there is no leakage or deformation after heavy rain and load tests.
