Customizable Moisture-proof Metal Carved Board For Movable Panel Houses
Customizable Moisture-proof Metal Carved Board For Movable Panel Houses
Specifications
Brand Name :
HY
Model Number :
09
Place of Origin :
Tianjin,China
MOQ :
1 piece
Payment Terms :
Prepayment starting from 30%
Supply Ability :
1000m per day (in stock)
Delivery Time :
3 days
Packaging Details :
Packaging of individual items
Style :
Modern
Waterproof grade :
IP65. The top and joints are sealed with ethylene propylene diene monomer (EPDM) rubber
Customization :
Customized as needed
Application :
K value ≤1.5W/(㎡ · K), and it can maintain an indoor temperature difference of ≤8℃ in an environment ranging from -10℃ to 40℃
Service life :
15 years
Fire resistance grade :
The wall panels and floors meet the B1 grade flame-retardant standard
Folded dimensions :
length 6000mm× width 2400mm× height 1600mm
Description

Customizable prefabricated movable panel houses - an efficient solution for temporary housing


Core Advantages: A Balance Between Lightweight Design and Practical Performance

Lightweight activity board houses adhere to the core design concept of "reducing weight without reducing quality". They adopt high-strength lightweight steel and new composite panels, with an overall weight reduced by more than 30% compared to traditional activity board houses, while still maintaining good structural stability. Their modular component design makes transportation more convenient and installation easier, especially suitable for scenarios with complex terrain and limited hoisting conditions. At the same time, the panels are made of environmentally friendly materials, with both moisture-proof and fire-resistant properties, ensuring practicality while meeting the requirements of modern temporary buildings for green environmental protection.


Key Parameter Configuration Table

Parameter Category Specification Details
Main Material Lightweight galvanized steel frame (wall thickness 1.2-1.5mm) + 50mm lightweight sandwich panel (core material is flame-retardant EPS)
Standard Single Set Size Length 5.9m × Width 2.8m × Height 2.7m (can be combined and expanded, single set self-weight only 0.8-1 ton)
Wind Resistance Level Level 6-7 (reinforced version can be upgraded to level 8)
Fire Resistance Level Sandwich panels meet B1 level flame-retardant standards, frames are treated with fireproof coatings
Single Set Bearing Capacity Uniform load ≥ 200kg/㎡ (meeting daily office and accommodation needs)
Installation Cycle A team of 2-3 people can complete the assembly of a single set within 8 hours
Transportation Efficiency A single 3.5-ton truck can load 5-6 sets of disassembled components (traditional board houses can only load 3-4 sets)
Service Life Main structure 8-12 years, sandwich panels 4-6 years

Application Scenarios: Diversified Applications Focusing on Lightweight Advantages

  • Mountain and High-Altitude Scenarios: Operation and maintenance houses for mountain photovoltaic power stations, temporary rest rooms for high-altitude operations, easy for manual handling and hoisting
  • Short-Term Mobile Scenarios: Outdoor houses for film crews, temporary houses for festival events, which can be quickly relocated with the project
  • Low-Load-Bearing Sites: Temporary offices on the roof, auxiliary houses for light workshops, reducing pressure on the foundation
  • Emergency Rapid Response: First-time resettlement sites after disasters such as earthquakes and floods, which can be quickly delivered by small vehicles

One-Sentence Q&A

  1. Will the lightweight design affect wind resistance?
    The regular version can resist level 6-7 winds, and the reinforced version can resist level 8 winds through structural optimization, meeting the needs of most temporary scenarios.
  2. Can a single set of board houses meet daily electricity needs?
    The pre-installed circuit system can be connected to 220V power supply, supporting the use of conventional electrical appliances such as lighting, air conditioners, and computers.
  3. Is it suitable for long-term outdoor placement?
    The panels are treated with anti-ultraviolet rays, and can be placed outdoors for 3-5 years without obvious aging (regular maintenance can extend the service life).
  4. What are the requirements for the ground during assembly?
    No need for hardened ground, flat land or simple wooden boards can be laid for placement, adapting to various terrains.
  5. How does the cost differ from traditional activity board houses?
    The single set purchase cost is slightly higher by 10%-15%, but the transportation and installation costs are reduced by 40%, making the comprehensive cost performance better.
