IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
Specifications
Battery Type :
LiFePO4, LiFePO4 (Hithium 314Ah Grade A)
Model Number :
LVB15WTC
Brand Name :
EXLIPORC
Place of Origin :
Guangdong, China
Dimension (L*W*H) :
1000X1300X2199mm
Weight :
2850kg±100kg
Communication Port :
RS485, RS-232, CAN
Protection Class :
IP55
Grid connection :
Off grid, Hybrid grid, On grid
Cooling :
Liquid Cooling
Nominal Energy :
261.12 kWh
Rated Power (PCS) :
125 kW
Configuration :
1P260S
Cooling Method :
Liquid Cooling (Water-Glycol)
Protection Level :
IP55
Cycle Life :
≥ 8,500 Cycles @ 0.5C/0.5C, 25°C, 80% SOH
Round Trip Efficiency :
≥ 90% (DC-DC)
Operating Temp :
-30°C to 50°C (with internal heating
Communication :
Ethernet / CAN / RS485 / WiFi / 4G
MOQ :
1
Price :
$28,986-33,210
Description
IP55 Liquid Cooled LiFePO4 BESS 125kW/261kWh Industrial Commercial Energy Storage System
Commercial & Industrial Energy Storage Solution designed for EPC contractors and industrial energy projects. This 125kW / 261kWh liquid-cooled BESS integrates battery, PCS, BMS, EMS, fire protection, and thermal management into one compact outdoor cabinet.
Key Specifications
  • Built on high-voltage 832V platform
  • Delivers stable 3-phase 400V output
  • ≤100ms switching time for seamless operation
  • Advanced liquid cooling system for precise temperature control
  • Battery life exceeding 8500 cycles
  • Wide operating temperature: -20°C to 50°C
  • Multi-level fire detection and automatic suppression
  • Water fire interface for industrial safety
  • Active/reactive power control capability
  • Harmonic suppression (THD <2%)
  • Black start capability
Applications
Ideal for peak shaving, solar integration, backup power, and microgrid projects. Pre-installed and factory tested with all-in-one design to reduce on-site installation time and simplify project deployment.
Note: For industrial and commercial use only. Not designed for residential applications.
Product Images
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
IP55 Liquid Cooled BESS 125kW/261kWh Industrial Commercial Energy Storage System
About EXLIPORC
Founded in 2017 and located in Shenzhen, EXLIPORC specializes in lithium battery solutions and provides comprehensive lithium battery services. Our professional teams focus on quality control, inspection, company operations, and after-sales service.
We have built a modernized high-quality management system in strict accordance with international standards. Our battery models are widely used in energy storage systems, commercial and industrial areas, E-bikes, E-scooters, RVs, golf carts, forklifts, and other transportation tools.
Since its foundation, EXLIPORC has always adhered to "quality of products in order to survive, credibility and development services" business purposes. We are committed to offering customers excellent services and products, taking responsibility throughout the entire service process.
Most of our models have gained international certifications including UL, TUV-CB, CE, ROHS, FCC, IEC62619, EMC, UN38.3 and MSDS. We continuously work to improve existing products and create new models according to customer requests.
Our mission is "Live Green, Save Green." We look forward to establishing long-term successful business relationships with clients worldwide.
