Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
Specifications
Battery Type :
Lithium Ion
Model Number :
LVB15WTC
Brand Name :
EXLIPORC
Place of Origin :
Guangdong, China
Dimension (L*W*H) :
1000X1300X2199mm
Weight :
2850kg±100kg
Communication Port :
CAN, RS485, RS-232
Protection Class :
IP54
Grid connection :
Off grid, Hybrid grid, On grid
Cooling :
Liquid Cooling
Product name :
Commercial & Industrial Liquid-Cooling Energy Storage
Battery type :
Lithium Iron Phosphate (LiFePO4)
Cell Brand & Type :
Hithium 314Ah Grade A Cells
Cycle life :
≥8500 cycles@25℃±2℃,0.5P,70%SOH
Cooling Method :
Smart Liquid Cooling (TMS Control)
Power Capacity :
125kW / 261.12kWh (Customizable)
Application Scenario :
Peak Shaving, EV Charging, Microgrid
BMS System :
3-Tier Intelligent Cloud BMS
Protection Rating :
IP54 Outdoor Cabinet (Anti-Corrosion C4)
Certification :
CE / UN38.3 / MSDS / IEC62477-1
MOQ :
1
Price :
$29,900-33,199
Description
Hithium Cell 125kW 261kWh Liquid Cooling BESS
Product Overview

Commercial & Industrial Energy Storage Solution designed for EPC contractors and industrial energy projects. This 125kW / 261kWh liquid-cooled BESS integrates battery, PCS, BMS, EMS, fire protection, and thermal management into one compact outdoor cabinet.

Key Features
  • Powered by Hithium 314Ah Cells: Ensures 11% higher energy density and 8,500+ cycle life
  • Advanced Liquid Cooling TMS: Precise temperature difference control within 3°C for maximum safety
  • Modular All-in-One Design: Pre-assembled and tested for fast plug-and-play installation
  • High-voltage 832V platform with stable 3-phase 400V output
  • ≤100ms switching time for seamless operation in grid-connected and off-grid scenarios
  • Wide operating temperature range: -20°C to 50°C
  • Multi-level fire detection and automatic suppression system
  • Supports active/reactive power control and harmonic suppression (THD <2%)
  • Black start capability for reliable backup power
Applications
  • Peak shaving for factories and industrial facilities
  • Solar integration and renewable energy storage
  • Backup power systems
  • Microgrid projects
  • Oil field operations
Installation Benefits

Pre-installed and factory tested, this all-in-one design significantly reduces on-site installation time and simplifies project deployment for industrial and commercial applications.

Note: For industrial and commercial use only. Not designed for residential applications.
Product Images
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
About EXLIPORC

Founded in 2017 and located in Shenzhen, EXLIPORC specializes in lithium battery solutions and provides comprehensive services including quality control, inspection, and after-sales support. The company operates a modernized high-quality management system in strict accordance with international standards.

Certifications & Quality
  • UL, TUV-CB, CE, ROHS, FCC certified
  • IEC62619, EMC, UN38.3 and MSDS compliance
  • Continuous product improvement and innovation
  • International quality standards adherence
Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System Hithium 261kWh Liquid Cooling BESS with 8500 Cycles for Commercial Energy Storage System
