Specifications
Battery Type :
LiFePO4
Model Number :
ESS-125/261-3P-N-B
Brand Name :
EXLIPORC
Place of Origin :
Guangdong, China
Dimension (L*W*H) :
1000X1300X2199mm
Weight :
2850kg±100kg
Communication Port :
CAN, RS-232, RS485
Protection Class :
IP54
Grid connection :
Hybrid grid, On grid, Off grid
Cooling :
Liquid Cooling
Cell Specification :
Hithium 314Ah Grade A LFP
System Configuration :
1P260S High Voltage Integrated
Thermal Management :
Advanced Liquid Cooling (TMS)
AC Rated Power :
125kW Three-Phase Output
Cycle Life :
≥8500 cycles@25℃±2℃,0.5P,70%SOH
Application Scenario :
Peak Shaving, Microgrid, Factory
System Efficiency :
≥90% Round-Trip Efficiency
Keywords :
Containerized ESS
Keywords 1 :
MWh storage
Keywords 2 :
Frequency response storage
MOQ :
1
Price :
$29,400-33,200
Description
125kW 261kWh Liquid Cooled BESS Hithium 314Ah C&I ESS for Factory Peak Shaving Solar
Product Overview

125kW/261kWh Liquid Cooling BESS for Commercial and Industrial (C&I) peak shaving applications. This industrial energy storage system maximizes savings through peak demand charge reduction and energy arbitrage strategies.

Key Features & Benefits
  • Industrial Energy Management: Ultimate solution for Factory Peak Shaving, reducing peak demand charges through Energy Arbitrage
  • Technical Core: Hithium 314Ah Grade A LFP technology with superior storage density compared to 280Ah units
  • Advanced Liquid Cooling: Thermal Management System maintains cell temperatures within ±3°C, preventing thermal runaway
  • All-in-One Integration: Built-in 125kW PCS with Smart EMS for real-time monitoring and peak-shaving logic
  • Extended Lifespan: 8,500+ cycles (15 years) with 20% lifespan extension through advanced cooling
  • Rugged Design: IP54 Outdoor Cabinet protection against dust and moisture
Technical Specifications
  • Power Output: 125kW
  • Energy Capacity: 261kWh
  • Battery Technology: Hithium 314Ah Grade A LFP
  • Cooling System: Liquid Cooling (TMS)
  • Cycle Life: 8,500+ cycles (15 years)
  • Standards Compliance: IEC 62619, CE, UN38.3
  • Enclosure Rating: IP54 Outdoor Cabinet
Applications
  • Factory Peak Shaving
  • Industrial Microgrids
  • Solar-Hybrid Power Projects
  • Demand Response Systems
  • Grid-Connected Microgrids
Product Images
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration 125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
About EXLIPORC

Founded in 2017 and located in Shenzhen, EXLIPORC specializes in lithium battery solutions and professional energy storage systems. With a modernized quality management system and international certifications including UL, TUV-CB, CE, ROHS, FCC, IEC62619, EMC, UN38.3 and MSDS.

Company Overview
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
Competitive Advantages
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
Factory Profile
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
Customization Capabilities
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
Project Cases
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
Packaging & Shipping
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
Trade Show Participation
125kW 261kWh Liquid Cooling BESS Energy Storage System for Factory Peak Shaving and Solar Integration
