2 Port 10/100M Industrial Ethernet Media Converter DIN Rail Mounting AC 220V Input
2 Port 10/100M Industrial Ethernet Media Converter DIN Rail Mounting AC 220V Input
2 Port 10/100M Industrial Ethernet Media Converter DIN Rail Mounting AC 220V Input
2 Port 10/100M Industrial Ethernet Media Converter DIN Rail Mounting AC 220V Input
2 Port 10/100M Industrial Ethernet Media Converter DIN Rail Mounting AC 220V Input
2 Port 10/100M Industrial Ethernet Media Converter DIN Rail Mounting AC 220V Input
Specifications
Brand Name :
MESTECHS
Model Number :
MFE20
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
Supply Ability :
200sets/week
Delivery Time :
45 work days
Price :
Negotiable
Packaging Details :
Common package
Input Power :
100~240VAC
Operating Temperature :
-40~75℃
Waterproof :
IP40
Switch Capacity: :
0.4Gbps
Material :
Fiber RJ45
Certification :
CE, FCC, RoHS
Description

MFE20 2-port 10/100M industrial Ethernet Media Converter DIN Rail Mounting Installation AC 220V input

MFE20 is 2-port 100M unmanaged industrial media converter. The product provides 100M copper port and 100M fiber port. It adopts DIN-Rail mounting to meet the requirements of different application scenes.

Hardware adopts fanless, low power consumption, wide temperature and voltage design and has passed rigorous industrial standard tests, which can suit for the industrial scene environment with harsh requirements for EMC. It can be widely used in smart grid, rail transit, smart city, safety city, new energy, aerospace, intelligent manufacturing, military project and other industrial fields.

Specification

Standard & Protocol

IEEE 802.3 for 10Base-T

IEEE 802.3u for 100Base-TX and 100Base-FX
Interface

Copper port: 10/100Base-T(X), RJ45, Automatic Flow Control, Full/Half Duplex Mode, MDI/MDI-X Autotunning

Fiber port: 100Base-FX, SC/ST/FC optional
LED Indicator

Port Indicator, Power Supply Indicator
Switch Property

Transmission mode: store and forward

MAC address: 2K

Packet buffer size: 0.5Mbit

Backplane bandwidth: 1.2G

Switch time delay: < 10μs
Power Requirement

12~48VDC, 3-pin 7.62mm pitch terminal blocks

Support nonpolarity, reverse polarity protection

Power Consumption

No-load: 1.20W@24VDC

Full-load: 1.37W@24VDC
Environmental Limit

Operating temperature: -40~75℃

Storage temperature: -40~85℃

Relative humidity: 5%～95%(no condensation)

Physical

Characteristic

Housing: IP40 protection, metal

Installation: DIN-Rail mounting

Dimension (W x H x D): 35mm×110mm×95mm

Weight: 340g
Industrial Standard

IEC 61000-4-2 (ESD), Level 4

Air discharge: ±16kV

Contact discharge: ±8kV

IEC 61000-4-5 (Surge), Level 4

Power supply, common mode ±4kV, differential mode ±2kV

Ethernet interface: ±4kV

Shock: IEC 60068-2-27

Free fall: IEC 60068-2-32

Vibration: IEC 60068-2-6
Certification

CE, FCC, RoHS
Warranty

5 years

2 Port 10/100M Industrial Ethernet Media Converter DIN Rail Mounting AC 220V Input

Order Information

Product Description Order Code

2-port 10/100M industrial Ethernet Media Converter MFE20
