Specifications
Brand Name :
MESTECHS
Model Number :
MFE20
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
Supply Ability :
200sets/week
Delivery Time :
45 work days
Price :
Negotiable
Packaging Details :
Common package
Input Power :
100~240VAC
Operating Temperature :
-40~75℃
Waterproof :
IP40
Switch Capacity: :
0.4Gbps
Material :
Fiber RJ45
Cable :
UTP and STP
Description

MFE20 2-port 10/100M industrial Ethernet Media Converter DIN Rail Mounting Installation AC 220V input

MFE20 is an industrial 100M fiber transceiver, the upload port is 100 megabytes single-mode single-fiber FC fiber interface, and the download port is 100 megabytes Ethernet port, which can realize the Ethernet electrical/optical signal mutual conversion, and carry out long-distance data and video signal transmission through optical fiber.

MFE20 upload uses wavelength division multiplexing technology, sending a wavelength of 1550nm and receiving a wavelength of 1310nm, simultaneously transmitting and sending data through a single-mode optical fiber, with a maximum transmission distance of 20km.

MFE20 adopts industrial design, supporting AC/220V power supply, wide operating temperature range, good reliability, outstanding quality, superior performance, Availible for residential areas, enterprises, roads, factories, mines, buildings and other monitoring scenarios. Recommend to use optical fiber transmission optical switch MFE200/400/600.

Feature

  • one 100-megabit FC fiber upload interface;
  • one 100-megabit RJ45 Ethernet port;
  • one AC / 220V power supply (European type terminal);
  • Based on WDM technology, single-mode single-fiber transmission, the longest transmission distance is 20km;
  • Working wavelength: 1550nm (sending), 1310nm (receiving)
  • Operating temperature: -40℃ ~ 70℃

Specification

Supported Standards

IEEE 802.3

IEEE802.3i

IEEE 802.3u

IEEE 802.3ab,IEEE 802.3z,IEEE 802.3x
Port One 100Mbps FC optical fiber interface
One 10Mbps/100Mbps adaptive port (RJ45)
AC / 220V power input (European type terminal)
Transmission wavelength TX:1550nm
RX:1310nm
Cable UTP and STP
Optical fiber 9/125um single-mode fiber
LED Optical and electrical port Link/Act, PWR
Power 220V/0.012A
Size 94.5mm*73mm*27mm
Operating temperature -40℃～70℃
Operating humidity 10% ~ 90%RH non-condensing
Storage temperature -40～85℃
Storage Humidity 5% ~ 90%RH non-condensing
Average transmitted power -14 ～ 7dBm
Receive sensitivity -32dBm
Data transfer rate per port 100 MBPS full-duplex

Superior Performance Ethernet Device , Industrial Din Rail Media Converter

Order Information

Product Description Order Code

2-port 10/100M industrial Ethernet Media Converter MFE20
