Specifications
Brand Name :
MESTECHS
Model Number :
AWR20
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
200sets/week
Delivery Time :
35 work days
Packaging Details :
Common package
interface :
RS232 RJ45 wifi
product form :
DTU
protocol :
TCP/IP,TCP,UDP
management :
web
Max session :
>20
Emission power :
12-15DBM
Description

AWR20 Serial to Ethernet to WiFi Converter DTU Small WiFi Serial Network Server RS232 to WiFi to RJ45 Network Port

AWR20 is a serial wifi router developed by Shenzhen mestechs Electronic Co.,Ltd .This product is based on the universal serial interface network standard, built-in TCP / IP protocol stack, enabling the user serial port, Ethernet, wireless network (wifi) interface between the conversions. Through the AWR20 the traditional serial devices do not need to change any configuration; data can be transmitted through the Internet network. Provide a quick solution for the user’s serial devices to transfer data via Ethernet.
Technical Specifications
Network standard wireless:IEEE 802.11n,IEEE 802.11g,IEEE 802.11b
wired:IEEE 802.3,IEEE 802.3u

Wireless transmission

rate

11n:maximum up to 150Mbps

11g:maximum up to 54Mbps

11b:maximum up to 11Mbps
Tracks number 1-14
Frequency range 2.4-2.4835G
Emission power 12-15DBM
Interface WAN LAN,RS232,DC IN,ANTENNA
Antenna
Antenna type Extemnal Antenna 6DB
Functional Parameters
WIFI work mode Client/AP/Router
WDS Function Support WDS wireless bridge connection
Wireless security

Wireless MAC address filtering

Wireless security function switch

64/128/152 bit WEP encryption

WPA-PSK/WPA2-PSK,WPA/WPA2 security mechanism
Network management

Remote Web management

Configuration file import and export

WEB software upgrade
Serial to Ethernet

Maximum transmission

rate

 500000bps
TCP connection Max connection number>20
UDP connection Max connection number>20
Senial baud rate 1200-500000bps
Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter
Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter
Product Outline
Theoutline of AWR20 serial WIFI serveris as follows.Mechanical Dimensions:
85x85x25 mm,not including the antenna.

Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter
External Interface
Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter


Application
Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter
Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter

Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter
Data Transmission Serial Port Converter , Serial To Ethernet To Wifi Converter

Order Information

Product Description Order Code

Serial to Ethernet to WiFi Converter ​AWR20
