153-9624、254-5147、235-2716 mining heavy equipment hydraulic pump axial piston main pump gear pump pilot adaptation 374F, 6015B, 988G, 966H
153-9624、254-5147、235-2716 mining heavy equipment hydraulic pump axial piston main pump gear pump pilot adaptation 374F, 6015B, 988G, 966H
153-9624、254-5147、235-2716 mining heavy equipment hydraulic pump axial piston main pump gear pump pilot adaptation 374F, 6015B, 988G, 966H
153-9624、254-5147、235-2716 mining heavy equipment hydraulic pump axial piston main pump gear pump pilot adaptation 374F, 6015B, 988G, 966H
Specifications
Model Number :
153-9624、254-5147、235-2716
Certifiion :
ISO
Place of Origin :
USA
MOQ :
1
Payment Terms :
MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100
Delivery Time :
2 weeks
Packaging Details :
wooden box
Outlet Port Position :
Top, Side, Bottom (customizable angle: 0°/90°/180°)
Axial piston pumps, gear pumps :
Match displacement to equipment power demand; higher cc/r = larger flow rate
Oil Cleanliness Grade :
Standard: NAS 9; Custom high-purity: NAS 6 (for precision control systems)
Seal Material :
Nitrile rubber (NBR, standard), Fluororubber (FKM, custom for high-temperature oil)
Rotation Direction :
Clockwise (CW, standard), Counterclockwise (CCW, custom order only)
Description
Mining Heavy Equipment Hydraulic Pump

Part Numbers: 153-9624, 254-5147, 235-2716

Axial piston main pump and gear pump pilot adaptation for 374F, 6015B, 988G, 966H and other equipment models

Technical Specifiions
Pump Type OEM Part Number Applicable Equipment Model Displacement (cc/r) Rated Pressure (MPa) Rotation Direction Mounting Standard
Axial Piston Pump 487-6207 301.5/301.6/301.7CR 12.5 28 Clockwise SAE A
Axial Piston Pump 423-0097 305.5E/306E/307E 65 32 Clockwise SAE B
Axial Piston Pump 272-6959 325D/329D/DL 145 35 Clockwise SAE C
Axial Piston Pump 369-9655 374F/390F 280 38 Clockwise SAE D
Axial Piston Pump 307-3063 415F/416F/422F 112 31 Clockwise SAE B
153-9624、254-5147、235-2716 mining heavy equipment hydraulic pump axial piston main pump gear pump pilot adaptation 374F, 6015B, 988G, 966H
Equipment Compatibility by Size egory
Mini Excavators (1-3 tons)

Main Pump: 487-6207 CA4876207, 566-7021, 241-7972, 163-9762, 241-9299

Adaptation: 301.5/301.6/301.7CR/301.8/302CR/302.5C/303.5, etc.

Pilot/Gear Pump: 560-0886, 211-6626

Small Excavators (3-10 tons)

Main Pumps: 423-0097, 397-3941, 214-1091, 4I-1023, 348-7627, 7Y-4002, 247-7867, 358-5004

Adaptation: 305.5E/306E/307D/308E/312D/317, etc.

Pilot/Gear Pump: 126-2016, 284-3536

Medium Excavators (20-36 tons)

Main Pumps: 272-6959, 289-7917, 272-6955, 259-0815/10 R-8707, 451-9302, 341-2860, 567-9721, 593-8367, 436-6669, 438-1293, 244-8479, 272-6957, 339-0513, 123-2233, 126-2073, 119-5407, 497-8499, 114-0602, 0R-8102

Adaptation: 320D/D2/323D2/326GC/329D/330D/336D/D2XE, etc.

Rotary Pumps: 204-4916, 204-4922

Pilot/Gear Pump: 175-6253, 397-6960

Large Excavators (over 37 tons)

Main Pump/Rotary Pump: 369-9655, 593-3840, 584-0380, 627-1304, 295-9426, 550-4341, 194-8259, 361-0718, 353-5691, 362-8488, 510-7950

Adaptation: 336GC/340/345/349/374F/385/390F/395GC, etc.

Pilot/Gear Pump: 564-9801, 234-4638

Frequently Asked Questions
What are the top causes of hydraulic pump failure?
Leading causes include hydraulic oil contamination, insufficient oil level/lubriion, long-term operation beyond rated pressure/flow, seal damage, and lack of regular maintenance.
Can aftermarket pumps replace OEM hydraulic pumps?
Yes, but only if the aftermarket pump matches the OEM model's displacement, rated pressure, mounting standard, and shaft specifiions. OEM parts are recommended for heavy-duty appliions to maintain warranty and performance.
How to extend the service life of a hydraulic pump?
Replace hydraulic oil and filters per the maintenance schedule, keep the system sealed to avoid contamination, monitor operating temperature (50-80°C optimal), and avoid dry starts or prolonged no-load high-speed operation.
Why is part number 487-6207 not suitable for excavators over 3 tons?
487-6207 is designed for mini-excavators (1-3 tons) with a small displacement that cannot meet the high-power demands of larger excavators.
What is the difference between a pump's OEM part number and its replacement number?
The OEM number is the original factory code, while replacement numbers (often prefixed with "CA-") are for upgraded/remanufactured versions that are fully compatible with the original equipment.
