≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
Specifications
Place of Origin :
China
Color :
Magenta
Supply Ability :
500pcs per 10 days
Connector A :
MTP Female UPC
Operating Wavelength :
850nm / 1310nm
Insertion Loss :
≤0.3dB (MTP), ≤0.2dB (LC)
Delivery Time :
7-15 days
Connector B :
4pcs LC Duplex UPC
MOQ :
100 pieces
Material :
OFNP Plenum / LSZH / PVC
Return Loss :
≥20dB for UPC multimode
Connector Type :
MTP Female UPC to 4pcs LC Duplex UPC
Brand Name :
DOWELL
Fiber Count :
8 Fibers
Payment Terms :
T/T
Length :
0.5m/1m/2m/3m/5m/10m...
Fiber Type :
OM4 multimode 50/125μm
Description
≤0.3dB MTP/MPO Female - LC OM4 Multimode Breakout Fiber Patch Cord
MTP female to 4 LC duplex 8-core OM4 breakout fiber patch cord is a high-density fan-out optical jumper specially engineered for modern data center high-speed cabling. Adopting standard OM4 multimode 50/125μm optical fiber with classic magenta outer sheath, one end is assembled with an MTP female connector, while the other end is evenly split into 4 groups of LC duplex connectors. The integrated strain relief boot at the branching point effectively guards internal fiber cores against excessive bending and pulling force. It greatly optimizes cabinet wiring layout, reduces messy cable accumulation, and is the ideal breakout solution for 40G/100G QSFP+ module splitting connection.
Specification
Insertion Loss ≤0.3dB (MTP), ≤0.2dB (LC)
Return Loss ≥20dB for UPC multimode
Operating Wavelength 850nm / 1310nm
Fiber Type OM4 Multimode 50/125μm
Features
  • OM4 multimode supports 100G transmission up to 150m distance under 850nm wavelength
  • Repeatable plugging over 1000 times, stable performance in long-term continuous use
  • 8 fibers integrated into one MTP connector, replace 8 single LC jumpers, reduce cable clutter in server rack
≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
Applications
  • 40G/100G QSFP+ to SFP+ module breakout connection, top-of-rack (TOR) switch cabling, server rack dense wiring
  • Optical transmission equipment, ODF fiber distribution box, passive optical splitter interconnection
  • Large-scale IP camera fiber aggregation, intelligent park backbone optical wiring
≤0.3dB MTP/MPO Female -LC OM4 Multimode Breakout Fiber Patch Cord
Frequently Asked Questions
Are you trading company or manufacturer?
70% of our products we manufactured and 30% do trading for customer service
How can you ensure the quality?
We are a one-stop manufacturer with complete facilities and over 15 years manufacturing experience to ensure product quality. We have passed ISO 9001 Quality Management System.
Can you provide samples? Is it free or extra?
Yes, after price confirmation, we could offer the free sample, but the shipping cost needs to be paid by your side.
How long is your delivery time?
In stock: within 7 days; Not in stock: 15-20 days, depending on your quantity.
Can you do OEM?
Yes, we can
What is your payment term?
Payment ≤4000USD, 100% in advance. Payment ≥4000USD, 30% TT in advance, balance before shipment.
How we can pay?
TT, Western Union, Paypal, Credit Card and LC
Transportation?
Transported by DHL, UPS, EMS, Fedex, Air freight, Boat and Train
