Specifications
Brand Name :
TIPTOP
Model Number :
JY Casing Scraper
Certification :
Inspection Certificate
Place of Origin :
China
MOQ :
1pc
Price :
Negotiation
Payment Terms :
T/T, L/C, D/A, D/P
Supply Ability :
1000 pcs per month
Delivery Time :
7-30 days
Packaging Details :
seaworthy wooden box
Casing Size :
4 1/2''~13 3/8''
Connection :
API
Application :
well completion
Scraping Range :
95.25-323mm
Type :
Oilfield Cementing Tool
Function :
Keep Casing Inner Surface Clean
Description

Well Completion Auxiliary Tool, JY Rotating Structure Casing Scraper

JY casing scraper is one of auxiliary tools in well completion, testing and downhole working. It is mainly used for cleaning cement, sand, residual bullets, rag, and other objects on casing inner surface, in order to keep casing inner surface cleaning and the drilling tools working normally. JY casing scraper can't be used in drilling operation.

It is one kind of new type casing scraper, not only as general fixed casing scraper, but also used as a rotating type structure casing scraper. If as a fixed casing scraper, as long as increase adjustable pad locates in upper sub to make it non-rotate, otherwise decrease adjustable pad. It will be used as a rotating casing scraper.

For any inquiries, please feel free to contact us.

Specification

Scraping Range (mm) OAL (mm) ID (mm) Connection Casing Size (inch)
95.25 960 16 2 3/8REG 4 1/2
101.6-116 1051 19 2 3/8REG 5
111-127 1067 19 2 7/8REG 5 1/2
136.5～163.5 1160 31.8 NC38 7
188.9～227 1241 71.4 NC50 9 5/8
314.3～323 1251 71.4 6 5/8REG 13 3/8
