Specifications
Brand Name :
DLX
Model Number :
FeCrAl Alloy Wire 0Cr15Al5
Certification :
Ce,Rohs
Place of Origin :
China,Jiangsu
MOQ :
10kg
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
500 tons per month
Delivery Time :
7-10 work days
Description

As the demand for green hydrogen accelerates, the need for efficient and reliable electrolysis systems has never been greater. At the heart of these systems lies 0Cr15Al5 FeCrAl Alloy Wire, a high-performance material designed to maximize the efficiency of hydrogen production through water electrolysis. This alloy wire, composed of a carefully balanced mix of iron, chromium, and aluminum, offers exceptional durability, corrosion resistance, and thermal stability, making it an essential component in modern electrolysis applications.

The 0Cr15Al5 FeCrAl Wire excels in harsh electrolytic environments, where it is exposed to extreme temperatures and aggressive electrolytes. Whether used in alkaline or high-temperature electrolysis, this wire ensures optimal performance, longevity, and cost-effectiveness, enabling industries to scale up hydrogen production in a sustainable manner.

Parameter Comparison Table
Alloy Nomenclature Performance 1Cr13Al4 0Cr25Al5 0Cr21Al6 0Cr23Al5 0Cr21Al4 0Cr21Al6Nb 0Cr27Al7Mo2
Chemical Compostion (%) Cr 12.0-15.0 23.0-26.0 19.0-22.0 20.5-23.5 18.0-21.0 21.0-23.0 26.5-27.8
Al 4.0-6.0 4.5-6.5 5.0-7.0 4.2-5.3 3.0-4.2 5.0-7.0 6.0-7.0
Re Opportune Opportune Opportune Opportune Opportune Opportune Opportune
Fe Rest Rest Rest Rest Rest Rest Rest

-- -- -- -- -- -- --
Max.Continuous service temp. of element 950 1250 1250 1250 1100 1350 1400
Resistivity at 20C(μΩ.m) 1.25 1.42 1.42 1.35 1.23 1.45 1.53
Density(g/cm) 7.4 7.1 7.16 7.25 7.35 7.1 7.1
Thermal Conductivity(KJ/m.h) 52.7 46.1 63.2 60.2 46.9 46.1 --
Coefficient of lines expansion(αx10-6/℃) 15.4 16 14.7 15 13.5 16 16
Melting Point Approx(degree) 1450 1500 1500 1500 1500 1510 1520
Tensile Strength(N/mm) 580-680 630-780 630-780 630-780 600-700 650-800 680-830
Elongation at rupture(%) >16 >12 >12 >12 >12 >12 >10
Variation of area(%) 65-75 60-75 65-75 65-75 65-75 65-75 65-75
Repeat Bending frequency(F/R) >5 >5 >5 >5 >5 >5 >5
Hardness(H.B.) 200-260 200-260 200-260 200-260 200-260 200-260 200-260
continuous service time(Hours/ ºC) -- ≥80/1300 ≥80/1300 ≥80/1300 ≥80/1250 ≥80/1350 ≥80/1350
Micrographic structure Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite Ferrite
Magnetic properties Magnetic Magnetic Magnetic Magnetic Magnetic Magnetic Magnetic
Shape Size (mm)
Wire 0.05-7.5
Rod 8-50
Ribbon (0.05-0.35)*(0.5-6.0)
Strip (0.5-2.5)*(5-180)
Key Features of 0Cr15Al5 FeCrAl Wire
  • Outstanding Corrosion Resistance: The 0Cr15Al5 FeCrAl Wire is engineered for resistance to oxidation and corrosion, even in harsh environments involving highly alkaline or acidic electrolytes, ensuring prolonged service life and minimal maintenance requirements.

  • High-Temperature Performance: With a melting point of 1,420°C, the alloy wire remains stable under extreme temperatures typically found in electrolysis systems, making it ideal for high-temperature electrolysis applications.

  • Superior Mechanical Strength: The wire's high tensile and yield strength provide structural integrity under the mechanical stresses and pressures common in electrolyzers, ensuring continuous operation without failure.

  • Thermal Stability: Excellent thermal conductivity and resistance to thermal cycling ensure that the wire performs efficiently even during frequent heating and cooling cycles in electrolysis processes.

  • Customizable Sizes: Available in a variety of diameters and lengths, the 0Cr15Al5 FeCrAl Wire can be tailored to meet the specific needs of different electrolysis systems, making it versatile and adaptable to various setups.

0Cr15Al5 FeCrAl Wire for Efficient Electrolysis in Hydrogen Production

Applications of 0Cr15Al5 FeCrAl Wire

The 0Cr15Al5 FeCrAl Wire is indispensable in several applications related to hydrogen production through electrolysis. Its combination of corrosion resistance, high strength, and thermal stability makes it suitable for diverse electrolysis processes:

  • Water Electrolysis for Hydrogen Production: The FeCrAl Alloy Wire is crucial for water electrolysis, where it facilitates the production of hydrogen by splitting water into hydrogen and oxygen, offering superior durability in aggressive electrolytes.

  • Alkaline Electrolysis: In alkaline electrolyzers, the 0Cr15Al5 FeCrAl Wire withstands the highly alkaline electrolytes, providing excellent corrosion resistance and ensuring longer operational life.

  • High-Temperature Electrolysis: The wire is well-suited for high-temperature electrolysis applications, capable of maintaining high performance even in elevated temperatures and intense reaction environments.

  • Fuel Cells and Energy Storage Systems: The FeCrAl Wire is also employed in fuel cell applications and energy storage technologies, where its high resistance to corrosion and thermal stability contribute to the efficient performance of electrochemical reactions.

  • Hydrogen Production R&D: Researchers involved in advancing hydrogen generation technologies depend on 0Cr15Al5 FeCrAl Wire to test and optimize electrolysis systems for improved hydrogen efficiency and sustainability.

Industry Trends and Applications

The hydrogen economy is growing rapidly as a critical element in the global push for renewable energy solutions. Electrolysis plays a central role in green hydrogen production, especially as the world moves toward decarbonizing industries such as transportation, power generation, and chemical manufacturing. The demand for green hydrogen is expected to rise significantly in the coming decades, driven by efforts to meet sustainability targets and reduce carbon emissions.

As hydrogen production technologies continue to evolve, electrolysis systems need high-performance materials that can withstand extreme operational conditions. The 0Cr15Al5 FeCrAl Wire is perfectly positioned to meet these demands, offering a reliable and durable solution for efficient and cost-effective hydrogen production.

The growing adoption of hydrogen as a clean fuel source in industries such as automotive and energy storage is further driving the need for efficient electrolysis systems. The FeCrAl Alloy Wire is an essential component in the development of these systems, contributing to the creation of a sustainable hydrogen economy.

Why Choose 0Cr15Al5 FeCrAl Wire?
  1. Enhanced Durability: The 0Cr15Al5 FeCrAl Wire is designed to withstand the harsh conditions of electrolysis systems, offering superior resistance to oxidation, corrosion, and high temperatures for a longer lifespan and reduced maintenance.

  2. Increased Hydrogen Production Efficiency: By providing consistent performance even in demanding environments, the FeCrAl Alloy Wire ensures that hydrogen generation is more efficient, maximizing system output while minimizing operational downtime.

  3. Adaptable to Different Electrolysis Systems: Available in various sizes, the 0Cr15Al5 FeCrAl Wire is customizable to fit different electrolysis setups, making it a versatile choice for a range of applications.

  4. Cost-Effective Solution: Although initially more expensive than other materials, the long-term cost savings due to the wire’s longevity and reduced maintenance requirements make it a cost-effective investment for hydrogen production.

  5. Contributing to Sustainable Energy: By enabling efficient green hydrogen production, the 0Cr15Al5 FeCrAl Wire helps advance the global transition to renewable, low-carbon energy solutions.

FAQs about 0Cr15Al5 FeCrAl Wire
  1. What is 0Cr15Al5 FeCrAl Wire made of?
    The 0Cr15Al5 FeCrAl Wire is made of a high-performance alloy consisting of iron (Fe), chromium (Cr), and aluminum (Al), providing excellent resistance to corrosion and high temperatures.

  2. How does the alloy wire perform in electrolysis systems?
    The 0Cr15Al5 FeCrAl Wire excels in electrolysis systems by resisting corrosion from both alkaline and acidic electrolytes, ensuring long-term performance in hydrogen production processes.

  3. Can the alloy wire be used in high-temperature electrolysis?
    Yes, with a melting point of 1,420°C, the 0Cr15Al5 FeCrAl Wire is ideal for high-temperature electrolysis applications, providing stable and reliable performance.

  4. How does the 0Cr15Al5 Alloy Wire improve hydrogen production?
    The wire’s corrosion resistance and high mechanical strength ensure consistent performance, increasing hydrogen production efficiency and reducing system downtime.

  5. Is the 0Cr15Al5 FeCrAl Wire customizable for different applications?
    Yes, the wire is available in a variety of sizes and can be tailored to meet the unique needs of different electrolysis systems, ensuring compatibility with a wide range of setups.

  6. What industries use 0Cr15Al5 FeCrAl Wire?
    It is used in hydrogen production, fuel cell technologies, energy storage, and various electrolysis systems, as well as in research and development for hydrogen generation technologies.

  7. How does the 0Cr15Al5 FeCrAl Wire contribute to sustainability?
    By enhancing the efficiency and longevity of electrolysis systems, the wire helps reduce the carbon footprint of hydrogen production, contributing to a greener, more sustainable energy future.

  8. What is the lifespan of 0Cr15Al5 FeCrAl Wire in electrolysis systems?
    The wire’s exceptional corrosion resistance and high thermal stability ensure a long lifespan, with fewer replacements required, reducing the total cost of ownership in electrolysis systems.
