STM8S103F3P6TR Access Line 8-bit MCU
16 MHz STM8S 8-bit microcontroller with up to 8 Kbytes Flash, data EEPROM, 10-bit ADC, 3 timers, UART, SPI, and I²C interfaces.
Key Features
Core Architecture
  • 16 MHz advanced STM8 core with Harvard architecture and 3-stage pipeline
  • Extended instruction set for enhanced performance
Memory Configuration
  • Program memory: 8 Kbyte Flash with 20-year data retention at 55°C after 10k cycles
  • Data memory: 640 byte true data EEPROM with 300k cycle endurance
  • RAM: 1 Kbyte for data storage
Clock, Reset and Power Management
  • Operating voltage: 2.95 to 5.5 V
  • Flexible clock control with 4 master clock sources:
    • Low power crystal resonator oscillator
    • External clock input
    • Internal, user-trimmable 16 MHz RC
    • Internal low-power 128 kHz RC
  • Clock security system with clock monitor
  • Power management features:
    • Low-power modes (wait, active-halt, halt)
    • Individual peripheral clock switch-off capability
  • Permanently active, low-consumption power on and power-down reset
Interrupt Management
  • Nested interrupt controller with 32 interrupts
  • Up to 27 external interrupts on 6 vectors
Timer Capabilities
  • Advanced control timer: 16-bit, 4 CAPCOM channels, 3 complementary outputs
  • Dead-time insertion and flexible synchronization features
Interrupt Vector Table
IRQ No. Source Block Description Wakeup from Halt Wakeup from Active-Halt Vector Address
- RESET Reset Yes Yes 0x00 8000
- TRAP Software interrupt - - 0x00 8004
0 TLI External top level interrupt - - 0x00 8008
1 AWU Auto wake up from halt - Yes 0x00 800C
2 CLK Clock controller - - 0x00 8010
3 EXTI0 Port A external interrupts Yes(1) Yes(1) 0x00 8014
4 EXTI1 Port B external interrupts Yes Yes 0x00 8018
5 EXTI2 Port C external interrupts Yes Yes 0x00 801C
6 EXTI3 Port D external interrupts Yes Yes 0x00 8020
7 EXTI4 Port E external interrupts Yes Yes 0x00 8024
