PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
Specifications
Brand Name :
NXP
Model Number :
PCA9685PW,118
Certification :
ROHS
Place of Origin :
CN
MOQ :
1
Price :
consult with
Payment Terms :
T/T,Western Union
Supply Ability :
10000
Delivery Time :
5-8day
Packaging Details :
T/R
Product Category: :
LED Display Drivers
Package / Case: :
TSSOP-28
Output Current: :
2.3V
Input Voltage - Max: :
5.5 V
Minimum Operating Temperature: :
- 40 C
Maximum Operating Temperature: :
+ 85 C
Low Level Output Current: :
25 mA
Description
PCA9685PW,118 16-channel, 12-bit PWM Fm+ I2C-bus LED Controller
Product Overview

The PCA9685PW,118 is a 16-channel, 12-bit PWM Fm+ I2C-bus LED controller designed for advanced LED driving applications with precise brightness control and flexible configuration options.

Key Features
  • 16 LED drivers with programmable outputs: Off, On, Programmable LED brightness, Programmable LED turn-on time to reduce EMI
  • 1 MHz Fast-mode Plus compatible I2C-bus interface with 30 mA high drive capability on SDA output
  • 4096-step (12-bit) linear programmable brightness per LED output
  • LED output frequency typically from 24 Hz to 1526 Hz (default 200 Hz refresh rate)
  • Sixteen totem pole outputs (sink 25 mA and source 10 mA at 5 V) with software programmable open-drain selection
  • Output state change programmable on Acknowledge or STOP Command
  • Active LOW Output Enable (OE) input pin with programmable output states
  • 6 hardware address pins supporting up to 62 devices on the same I2C-bus
  • Hardware LED blinking capability via OE toggling
  • 4 software programmable I2C-bus addresses with group addressing capabilities
  • Software Reset feature (SWRST General Call) for I2C-bus reset
Package Information
Type Number Topside Mark Package Name Description Version
PCA9685PW PCA9685PW TSSOP28 plastic thin shrink small outline package; 28 leads; body width 4.4 mm SOT361-1
PCA9685PW/Q900[1] PCA9685PW TSSOP28 plastic thin shrink small outline package; 28 leads; body width 4.4 mm SOT361-1
PCA9685BS P9685 HVQFN28 plastic thermal enhanced very thin quad flat package; no leads; 28 terminals; body 6 × 6 × 0.85 mm SOT788-1
