TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller
TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller
TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller
TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller
TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller
TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller
Specifications
Brand Name :
TI
Model Number :
TMS320F28335PGFA
Certification :
rohs
Place of Origin :
CN
MOQ :
1
Price :
consult with
Payment Terms :
T/T,Western Union
Supply Ability :
100000
Delivery Time :
5-8days
Packaging Details :
T/R
Product Category: :
MCU
Max Speed (MHz) :
150MHz
Data Bus Width: :
32 Bit
Program Memory Size: :
512KB
Data RAM Size: :
34KB
operating voltage :
1.805V~1.995V
Number of I/Os: :
88
Description
TMS320F28335PGFA Digital Signal Processors & Controllers

High-performance DSP DSC Digital Signal Controller with advanced processing capabilities for industrial applications.

Key Features
  • High-performance static CMOS technology - Up to 150 MHz (6.67-ns cycle time), 1.9-V/1.8-V core, 3.3-V I/O design
  • High-performance 32-bit CPU (TMS320C28x) - IEEE 754 single-precision Floating-Point Unit, 16*16 and 32*32 MAC operations, 16*16 dual MAC, Harvard bus architecture
  • Six-channel DMA controller - For ADC, McBSP, ePWM, XINTF, and SARAM
  • 16-bit or 32-bit External Interface (XINTF) - More than 2M*16 address reach
  • Comprehensive on-chip memory - Flash memory up to 256K*16, SARAM up to 34K*16, 1K*16 OTP ROM
  • Boot ROM (8K*16) - Software boot modes through multiple interfaces with standard math tables
  • Advanced clock and system control - On-chip oscillator and watchdog timer module
  • Extensive GPIO capabilities - GPIO0 to GPIO63 pins with external core interrupt support
  • Peripheral Interrupt Expansion (PIE) block - Supports all 58 peripheral interrupts
  • 128-bit security key/lock - Protects flash/OTP/RAM blocks and prevents firmware reverse-engineering
  • Enhanced control peripherals - Up to 18 PWM outputs, 6 HRPWM outputs with 150-ps MEP resolution, 6 event capture inputs, 2 Quadrature Encoder interfaces, and multiple timer options
Part Number and Package Specifications
Part Number Package Body Size
TMS320F28335ZAYnFBGA (179) 12.0 mm * 12.0 mm
TMS320F28334ZAYnFBGA (179) 12.0 mm * 12.0 mm
TMS320F28234ZAYnFBGA (179) 12.0 mm * 12.0 mm
TMS320F28232ZAYnFBGA (179) 12.0 mm * 12.0 mm
TMS320F28335ZHHBGA MicroStar (179) 12.0 mm * 12.0 mm
TMS320F28334ZHHBGA MicroStar (179) 12.0 mm * 12.0 mm
TMS320F28332ZHHBGA MicroStar (179) 12.0 mm * 12.0 mm
TMS320F28235ZHHBGA MicroStar (179) 12.0 mm * 12.0 mm
TMS320F28234ZHHBGA MicroStar (179) 12.0 mm * 12.0 mm
TMS320F28232ZHHBGA MicroStar (179) 12.0 mm * 12.0 mm
TMS320F28335ZJZBGA (176) 15.0 mm * 15.0 mm
TMS320F28334ZJZBGA (176) 15.0 mm * 15.0 mm
TMS320F28332ZJZBGA (176) 15.0 mm * 15.0 mm
TMS320F28235ZJZBGA (176) 15.0 mm * 15.0 mm
TMS320F28234ZJZBGA (176) 15.0 mm * 15.0 mm
TMS320F28232ZJZBGA (176) 15.0 mm * 15.0 mm
TMS320F28335PGFLQFP (176) 24.0 mm * 24.0 mm
TMS320F28334PGFLQFP (176) 24.0 mm * 24.0 mm
TMS320F28333PGFLQFP (176) 24.0 mm * 24.0 mm
TMS320F28332PGFLQFP (176) 24.0 mm * 24.0 mm
TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller TMS320F28335PGFA Digital Signal Processors & Controllers - DSP DSC Digital Signal Contr Oller
Packaging & Shipping

Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.

Frequently Asked Questions
How to obtain the price?

We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.

What is your delivery time?

Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.

What are your payment terms?

Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.

What are the shipping options?

Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
