Specifications
Brand Name :
CJ
Model Number :
CESD5V0D5
Place Of Origin :
CN
Certification :
ROHS
MOQ :
1
Price :
consult with
Payment Terms :
Western Union,T/T
Supply Ability :
10000
Delivery Time :
5-8day
Packaging Details :
T
Brand :
CJ
Reverse Cut-offVoltage (Vrwm) :
5V
Clamp Voltage :
13V
Pulse PeakCurrent (lpp) :
13A
Peak PulsePower (Ppp) :
170W@8/20us
Breakdown Voltage :
6.2V
Description

CESD5V0D5 Uni-direction ESD Protection Diode Designed To Protect Voltage Sensitive Electronic Components From ESD And Othertransients

Product Features
  • Uni-directional ESD protection of one line
  • Reverse stand−off voltage: 5V
  • Low reverse clamping voltage
  • Low leakage current
  • Excellent package:1.2mm*0.8mm*0.6mm
  • Fast response time
  • JESD22-A114-B ESD Rating of class 3B per humanbody model
  • IEC 61000-4-2 Level 4 ESD protection
Applications
  • Computers and peripherals
  • Audio and video equipment
  • Cellular handsets and accessories
  • Portable electronics
  • Other electronics equipments communication systems
ESD Class Human Body Discharge
ESD Class Human Body Discharge V
0 0～249
1A 250～499
1B 500～999
1C 1000～1999
2 2000～3999
3A 4000～7999
3B 8000～15999
CESD5V0D5 Uni-direction ESD Protection Diode Designed To Protect Voltage Sensitive Electronic Components From ESD And Othertransients CESD5V0D5 Uni-direction ESD Protection Diode Designed To Protect Voltage Sensitive Electronic Components From ESD And Othertransients CESD5V0D5 Uni-direction ESD Protection Diode Designed To Protect Voltage Sensitive Electronic Components From ESD And Othertransients CESD5V0D5 Uni-direction ESD Protection Diode Designed To Protect Voltage Sensitive Electronic Components From ESD And Othertransients
Packaging & Shipping

Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.

Frequently Asked Questions

How to obtain the price?

We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.

What is your delivery time?

Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.

What are your payment terms?

Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.

What are the shipping options?

Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
